Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604

Categories Metallurgical Optical Microscope
Place of Origin: China
Brand Name: CNOEC, OPTO-EDU
Certification: CE|Rohs
Model Number: A13.2604
MOQ: 1 pc
Price: FOB $1~1000, Depend on Order Quantity
Packaging Details: Carton Packing, For Export Transportation
Delivery Time: 5~20 Days
Payment Terms: T/T, West Union, Paypal
Supply Ability: 5000 pcs/ Month
application: Research|Learning|Metallurgical
Drawtube: Trinocular
Illumination: Halogen Lamp
magnification: 50x - 1000x
Theory: Metallurgical Optical Microscope
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604


Learning Infinity Plan Microscope Trinocular Compound Microscopes Rohs A13.2604



Description:

A13.2604 Metallurgical Microscope

--Infinity optical system for metallurgical observing
--Stress Free Long working distance objective
--Reflecting & transmitting light source available
--Polarizing Set Included
--Kohler illumination collector with field diaphragm


Specifications:

Specification
A13.2604 Metallurgical Microscope
A
B
HeadTinocular, inclinded 30°, interpupillary distance 50-75mm
●
●
EyepieceWF10X/18mm
●
●
WF10X -18 mm (Reticule 0.1mm)
●
●
ObjectiveInfinity Plan Metallurgical Objective
(no cover glass)
5x/0.1, WD=6.73mm
●
●
10x/0.25, WD=4.19mm
●
●
20x/0.4(s), WD=2.14mm
●
●
100x/1/25(oil)(s), WD=0.12mm
●
LWD Infinity Plan Metallurgical Objective (no cover glass)40x/0.65(s), WD=3.90mm
●
●
NosepieceQuintuple Backward
●
●
StageMechnical Stage for Reflection Illumination, Size: 190×140mm, Travel Range: 78×55mm, Stage Fast Lowing Unit, Stage Up-Down moving range 50mm (Max.)
●
Mechnical Stage for Transmit llumination, Size: 190×140mm, Travel Range: 78×55mm, Coaxial Coarse and Fine Focusing Knobs
●
PlateStage Plate: Place The Sample on The Plate
●
●
Clip
●
PolarizingPolarizing /Analyzer Slide
●
●
CondenserAbbe N.A. 1.25, with iris diaphragm
●
FocusingCoaxial coarse and fine focusing knob, coarse focusing range 25mm, fine focusing scale 2um, with tension adjustment
●
●
Light SourceReflecting light, 12V 50W halogen lamp
●
●
Transmiting light, 6V 20W halogen lamp, Center Adjustable Kohler Collector
●
CollectorKohler illumination collector with field diaphragm
●
FilterBlue
●
Packing1pc/carton, size 75x36x45cm, G/N weight 16/15Kgs
●
●
Optional Accessories
Item No.
EyepieceWF 5x/20mmA51.2602-05
WF12.5x/14mmA51.2602-125
WF16x/13mmA51.2602-1613
ObjectiveInfinity Plan Metallurgical Objective
(no cover glass)
40x/0.65(s),WD=0.45mmA5M.2632-40
LWD Infinity Plan Metallurgical Objective
(no cover glass)
20x/0.4(s),WD=8.35mmA5M.2633-20
50x/0.7(s),WD=1.95mmA5M.2633-50
80x/0.8(s),WD=0.85mmA5M.2633-80
StageGlass Plate for Transmit LightA54.2605
Stage Micrometer 0.01mmA58.2601
AdapterC-Mout 0.5xA55.2601-MT05
C-Mout 1.0xA55.2601-MT10
