Fire Pump For Marine

2400m3/h sea water fire pump for fifi1 /fi-fi class 1system

Type:Horizontal mounted single stage Double side

suction,top discharge centrifugal pump

Model: HYCXB400-350

Medium: Seawater

Capacity: 2400 m3/h

Pump head: 130m

Pump speed: 1800 r/min

Power absorbed: 1100kw

Pump efficiency: 80%

Dimension of pump inlet: DN400

Dimension of pump outlet: DN350

Material:

Pump shell: Nodular cast iron

Impeller: Ni-Al bronze

Shaft: Stainless Steel

Bearing: SKF

Shaft sealing: Soft sealing

Chongqing Gathering Marine Equipment Co.,Ltd has progressed and grown to become a leading supplier of approved &certificated water treat equipment ,  life saving equipment , FFE , marine engine , marine thruster  worldwide . we offer quality products at competitive prices and have an excellent after sales service , we are a dedicated team and strive to achieve a very high standard of satisfaction

 Our company, founed in 2007, specializes in supplying a broad range of marine and fire fighting products. These products are approved by the standard of SOLAS, MED,  CCS, GL-EC, RS, USCG,BV,DNV ,etc

We have creditworthy and high standard of service to meet our clients requirements
