| Categories | Heavy Truck- Water Tanker Truck |
|---|---|
| Place of Origin: | CHINA |
| Brand Name: | HOWO |
| Vehicle Main Dimensions | Overall Dimensions(LxWxH)mm | 8610x2496x3300 |
| Wheel Base(mm) | 4325+1350 | |
| Wheel Track(front/rear)(mm) | 1500/2625 | |
| Approach/Departure Angle(°) | 16/15 | |
| Weight (KG) | Tare Weight | 11000 |
| Payload | 13750 | |
| Front Axles Loading Capacity | 1x7000 | |
| Rear Axles Loading Capacity | 2x16000 | |
| Max. Driving Speed | 90km/h | |
| Engine | Brand | SINOTRUK |
| Model | WD615.69 | |
| Type | 4-stroke direct injection, 6-cylinder in-line, turbo-charging and inter-cooling | |
| Horse Power(hp) | 336hp | |
| Emission Standard | EURO II | |
| Gearbox | 10 forwards gear and 2 reverse gear | |
| Steering | Power Steering ZF8098 from Germany | |
| Tire | 12.00-20 bias tyre | |
| Cabin | HW76, with one sleeper and air condition, 70° hydraulically tippable to the front. | |
| Tank Specification | 10000 liters, tank thickness is 4mm, seal is 5mm | |
| Equipped with front(rear, side) sprinkler(sprinkling width＞14m) | ||
| Equipped with rear working platform with water cannon(range＞28m) | ||
| Equipped with pump(suction lift＞6m) | ||
| Equipped with fire valve, water valve, and filter gauze | ||
| Production Cycle | 20 days | |
| Water pump, front spouting, rear sprinkling, rear platform, water monitor, side spouting and fire hydrant, no self-flow pipe, | ||
| One tanker cover, power take-off | ||
| Tank, pump or pipes can be made by stainless, all sprinkler can be removed to be a water transportation vehicle. | ||
| Water transportation vehicles(no sprinkler) can be made from 10m3 with 4x2 driving type, to 28m3 with 8x4 driving type. But for a sprinkling water tanker, 20m3 with 6x4 model is the biggest, because it will be unstable if bigger. | ||
|
