| Brand Name: | LINK-PP |
| Model Number: | HY601680 |
| Certification: | UL,RoHS,Reach,ISO |
| Place of Origin: | Guangdong,China |
| MOQ: | 400/2000/10K/25K |
| Price: | $0.06-$3.2 |
| Payment Terms: | TT,NET30/60/90 Days |
| Supply Ability: | 3KK/Month |
| Delivery Time: | Stock |
| Packaging Details: | T&R |
| Speed: | 10/100 Base-T |
| Turns Ratio: | 1 : 1 Transmitter, 1 : 1 Receiver |
| Number of Ports: | Single Port |
| Mounting Type: | Surface Mount |
| Case Material: | DAP |
| Solderability: | 240±5℃ molten solder for 3±0.5 seconds |
| Company Info. |
| LINK-PP INT'L TECHNOLOGY CO., LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
Elevate your connectivity experience with the HY601680 Surface
Mount Transformer Module. It operates seamlessly at 10/100 Base-T
speed for reliable data transmission in different network
environments. With a balanced 1:1 Turns Ratio for both the
transmitter and receiver, this Ethernet Transformer guarantees
optimal signal integrity. Adopting a single-port design, it is
simple and convenient to operate in various network applications.
Facilitates easy integration with its Surface Mount design,
allowing for simple installation and flexible placement. Dipped in
240±5℃ Molten Solder For 3±0.5 Seconds, 95% minimum, shall be
smooth and bright.
| Items | 10/100Base-T Single Port Transformer Module |
|---|---|
| RoHs Status | RoHS Compliant (Pb Free) |
| Isolation | 1500Vrms 0.5mA 60sec (Primary to Secondary) |
| Meets or Exceeds EEE802.3 standards including 350uH Min OCL with 8mA DC | |
| Insertion Loss | -1.1dB Maximun @300KHz ~ 100MHz |
| Return Loss | -20dB Typical @30NHz -14dB Typical @60MHz -11.5dB Minimum @80MHz |
| Different to Common Mode Rejection | -37dB Typical @30MHz ~ 50MHz -30dB Typical @100MHz |
| Crosstalk | -45dB Typical @1MHz ~ 30MHz -35dB Typical @60MHz ~ 100MHz |
| Case material | DAP |
| Solderability | Dipped in 240 ± 5°C molten solder for 3 ± 0.5 seconds, 95% minimum, shall be smooth and bright. |
| Operating Temperature | 0°C - +70°C |
