20mm Micro Lightweight DC Blower Fan 0 . 45 / 0 . 66CFM Air Flow

Categories DC Blower Fan
Brand Name: MX
Model Number: MX2008GNH5
Certification: CE UL ROHS
Place of Origin: GUANGDONG / CHINA
MOQ: 2000pcs
Price: USD + 1 / 5 + Piece
Payment Terms: Western Union, T/T , PayPal
Supply Ability: 10000 + Piece + A Day
Delivery Time: 7 - 10 Working Days
Packaging Details: Carton Box
Color: Black
Frame and Imoeller: P . B . T
Bearing Type: Axially - Grooved Bearing
Voltage: 3 . 3V / 5 . 0V
Expected Life: 20000 hours
Speed: 11000 / 7500 RPM More or Less 15%
Air Flow: 0 . 45 / 0 . 66CFM
Noise Level: 10 / 14dBA
Rated Current: 55 / 75 mA More or Less 10%
Weight: 2 . 9G
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

20mm Micro Lightweight DC Blower Fan 0 . 45 / 0 . 66CFM Air Flow


20mm Micro Lightweight DC Blower Fan 0 . 45 / 0 . 66CFM Air Flow




(Specification and Features)
SPECIFICATION
Model NumberMX2008GNH5
Product NameMicro Blower
Rated Voltage (VDC)3 . 3V5V
Operating Voltage (VDC)2 . 8v - 5 . 5V
Rated Current (mA)90 ± 10%130 ± 10%
Rotation Speed (RPM)7500 ± 15%11000 ± 15%
Air Flow (CFM)0 . 450 . 66
Static Pressure (mmAq)5575
Noise (dB(A)) at 1m1014
Insulation Resistance10MEGA. Ω Min. at 500VDC (between frame and (+) terminal)
Dielectric Strength5mA Max. at 500VAC , 60Hz , One Minute (between frame and (+) terminal)
Life Expectancy (hours)25,000 at 45
IP RatingIP58
ComplianceCE , RoHS
Weight (g)2 . 9
ProtectionLock rotorPolarity

Specifications subject to changes without notice.

Operating Temperature : -10℃ - +60℃


(Main Parts and Materials List)
Name of PartMaterial
FrameP.B.T.+30% Glass fiber (UL94V-0)
SpacerMylar
BearingCu-based composite powder
IC Hall ICN/A
PCBGlass epoxy
Surface-mounted CoilUEW copper wire Aluminum oxide
Fan BladeP.B.T.+30% Glass fiber (UL94V-0)
ShaftSUS 420F
YokeSUS430
MagnetRare earth magnet
CoverP.B.T.+30% Glass fiber (UL94V-0)
Position plateSUS430
Lead-wire setUL1571 AWG#32 Tin-coated copper
LabelMatte metallized polyester


Integrated Monitoring Software/Hardware



Competitive Advantage:

* Qualified, cost effective and easily operated

* Small in shape, have compact structure

* UL, CE, Rohs, CUL, CCC

* Competitive Pricing

* Keep Investing and Developing In New Products

* The Most Advanced Testing and Measuring Equipment

* On-Time Delivery
