Belfuse SI-51005-F Magjack Rj45 With Integrated Magnetics and Leds LPJG17332AWNL

Belfuse SI-51005-F Magjack Rj45 With Integrated Magnetics and Leds LPJG17332AWNL

Belfuse SI-51005-FElectrical Specifications:
1.Turns Ratio(%%P2%):
1CT:1CT
2.Inductance: 350uH Min
@100KHz,0.1V,8mA DC BIAS
3.Insertion Loss:
0.1-100MHz:-1.2dB Max
4.Return Loss(dB Min):
0.5-40MHz:-18
40-100MHz:-12+20LOG(f/80MHz)
5.Cross Talk(dB Min):
1-30MHz:-35 30-80MHz:-24
80-100MHz:-25
6.CM TO CM REJECTION:
0.1-100MHz:-30dB Min
7.CM TO DM Rejection:
0.1-100MHz:-35dB MIN
8.Hipot: 1500Vrms.
9.Operating Temperature: 0℃～70℃
