Cantilever H Beam Welding Machine Automatic 6 - 60mm Thickness

Cantilever H Beam Welding Machine Automatic 6 - 60mm Thickness

1. Brief introduction

The whole machine adopts the structure of cantilever trolley driving way, the main machine combined with traveling structure, cantilever frame body, electric-motion pole lifting structure and level moving structure, arc guiding structure, flux auto recycling system, auto submerged arc welding system, electric control system and so on. This machine is driven by frequency conversion motor system, which drags the whole trolley to do level moving. The flux recycling system recycle the flux and use it again.

2. Technical parameters

● Height of the web: 200-2000mm
● Thickness of the web: 6-60mm
● Width of the flange: 200-800mm
● Thickness of the flange: 6-80mm
● Rail span: 1600mm
● Main machine power: 6KW (not include welding machine)
● Welding speed: 350-1500mm/min
● The maximum empty traveling speed: 3500mm/min

3. Supply range

● Machine assembly: basis seat, traveling structure, transverse slippage structure, wire feeder wheel and so on.
● Welding assembly: up-down guide pole, wire feeder machine rack.
● Arc guide assembly: welding torch, transverse moving structure and accessories.
● Flux recycling system: electrical control box, AC frequency conversion driving system.
● Power transmission assembly: tank chain and accessories.
● Welding machine: MZ-1000 submerged arc welder (1 set).
