45 Degree 90 Degree Stainless Steel Elbow 1” 12” SCH10S To SCH40S SCH80S

ASTM A403 WP317L 45º / 90º Elbow Stainless Steel Elbow 1” 12” SCH10S To SCH40S SCH80S ASME B16.9

Quick Detail:

· Material:Stainless Steel

· Technics:Forged

· Type:Elbow

· Connection:Welding

· Shape:Equal

· Head Code:Round

· Size:1/2"-72"

· Pressure:sch10-xxs

· Angle:22.5° ,30°, 45°, 60°,90°,180° degree

· Application:Petroleum chemical machinery electric power, papermaking, etc

· Standard:ASME ANSI MSS-SP JISB DIN BS GB

· Packing:in wooden cases, pallets,or as for clients'requirements

· Radius: Short radius,Long radius

· Qualification:API,ISO,CE

· Surface treatment:Natural

Description:

1. Product Item No.: 003fittings-Cosco Steel

2. The product have been mainly used in Petroleum & Gas,chemical plant,power station,metallurgy,shipbuilding,etc.

3. Strictly production process,under the ISO9001:2008 quality contral system guidelines.

4. MTC certification as per EN10204 3.2.1.

5. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size

6. Packing: Wooden box or wooden pallet.

7. H.S Code: 73072300

Product

Elbow Type

Long or short radius.

22.5° ,30°, 45°, 60°,90°,180° degree,

Butt welding elbow, Forging threaded elbow, Street elbow.

Size Butt weldingDN: DN10~DN 1200 WT: SCH10-XXS

Forging

DN:DN10~DN150

Pressure class : 150LBS~10000LBS

Standard

ANSI B16.5, B16.11, B16.3,

ASTM A234/A234M, ASTM A403/A403M, ASTM A420/A420M, ASTM A182/A182M, DIN2605, JIS B2311, JIS B2312. HG,GB,SH,HGJ,JB,ANSI,JIS,DIN

Material

A105, WPB, WPC, WP1, WP12, WP11, WP22, WP5, WP9, WPR, WP91, WP304, WP304L, WP309, WP310, WP316, WP316L, WP317, WP317L, WP321, WP347,WP348, WPL3, WPL6, WPL8, WPL9, F1, F5, F1

Material:

Material

ASTM

Carbon steel(ASTM A234WPB,,A234WPC,A420WPL6.

Stainless steel(ASTM A403 WP304,304L,316,316L,321. 1Cr18Ni9Ti,

00Cr19Ni10,00Cr17Ni14Mo2, ect.)

Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5,
A420WPL6,A420WPL3

DIN

Carbon steel:St37.0,St35.8,St45.8

Stainless steel:1.4301,1.4306,1.4401,1.4571

Alloy steel:1.7335,1.7380,1.0488(1.0566)

JIS

Carbon steel:PG370,PT410

Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321

Alloy steel:PA22,PA23,PA24,PA25,PL380

10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo,
12CrMo, 12CrMoG, 12Cr1Mo

size	Outer Diameter (OD)	Wall thickness (T)				90^o L / R Elbow center to tail A	45^o L / R center to bend the tail end B	90^o S / R to the end of A Center Elbow	Three links to the Center for the tail end C.M	The length of the cap E
size	Outer Diameter (OD)	Sch.5S	Sch.10S	Sch.40S	Sch.80S	90^o L / R Elbow center to tail A	45^o L / R center to bend the tail end B	90^o S / R to the end of A Center Elbow	Three links to the Center for the tail end C.M	The length of the cap E
1/2	0.840	0.065	0.083	0.109	0.147	1.50	0.625	-	1.00	1.00
3/4	1.050	0.065	0.083	0.113	0.154	1.12	0.438	-	1.13	1.00
1	1.315	0.065	0.109	0.133	0.179	1.50	0.875	1.00	1.50	1.50
1-1/4	1.660	0.065	0.109	0.140	0.191	1.88	1.00	1.25	1.88	1.50
1-1/2	1.900	0.065	0.109	0.145	0.200	2.25	1.12	1.50	2.25	1.50
2	2.375	0.065	0.109	0.154	0.218	3.00	1.38	2.00	2.50	1.50
2-1/2	2.875	0.083	0.120	0.203	0.276	3.75	1.75	2.50	3.00	2.00
3	3.500	0.083	0.120	0.216	0.300	4.50	2.00	3.00	3.38	2.50
4	4.500	0.083	0.120	0.237	0.337	6.00	2.50	4.00	4.13	3.00
5	5.563	0.109	0.134	0.258	0.375	7.50	3.12	5.00	4.88	3.50
6	6.625	0.109	0.134	0.280	0.432	9.00	3.75	6.00	5.63	4.00
8	8.625	0.109	0.148	0.322	0.500	12.00	5.00	8.00	7.00	5.00
10	10.750	0.134	0.165	0.375	0.500	15.00	6.25	10.00	8.50	6.00
12	12.750	0.156	0.180	0.375	0.500	18.00	7.50	12.00	10.00	7.00
14	14.000	0.156	0.250	0.375	0.500	21.00	8.75	14.00	11.00	7.50
16	16.000	0.165	0.250	0.375	0.500	24.00	10.00	16.00	12.00	8.00
18	18.000	0.165	0.250	0.375	0.500	27.00	11.25	18.00	13.50	9.00
20	20.000	0.188	0.250	0.375	0.500	30.00	12.50	20.00	15.00	10.00
24	24.000	0.218	0.250	0.375	0.500	36.00	13.50	24.00	17.00	12.00

ASME B16.9

Applications range: For use in the petroleum, smelting, foodstuff, power, papermaking, chemical, medical equipment, aviation, boiler heat exchanger, and other fields.
Note:Providing customers with customerized composition,size,package.

Specification

ND		OD(MM)	Center to end		Approx Weight KG/PCS
DN	INCH	OD	A	O	5S	10S	20S	40S	80S
20	3/4	25 20.7	-	-	-	-	-	-	-
25	1	32 33.4	25	50	0.055	0.096	0.11	0.11	0.15
32	11/4	38 42.2	32	64	0.069 0.075	0.102 0.132	0.14 0.15	0.158 0.17	0.20 0.236
40	11/2	45 48.3	38	76	0.12 0.13	0.18 0.186	0.2 0 .21	0.22 0.24	0.3 0.33
50	2	57 60.3	51	102	0.17 0.176	0.297 0.308	0.787 0.396	0.42 0.44	0.6 0.616
65	21/2	73 76.1	64	128	0.35 0.364	0.53 0.546	0.64 0.655	0.89 0.91	1.0 1.29
80	3	89	76	152	0.486	0.729	0.972	1.36	1.94
90	31/2	101.6	89	178	0.7	1.05	1.4	1.96	2.8
100	4	108 114.3	102	204	0.90 0.94	1.2 1.4	1.7 1.876	2.56 2.77	4.0 4.13
125	5	133 141.3 139.7	127	254	1.8 2.02	2.1 2.37	3.2 3.49	4.0 4.4	6.5 6.98
150	6	159 168.3 165.2	152	304	2.6 2.9	3.1 3.4	4.8 5.0	6.8 7.1	10.3 11.0
200	8	219 216.3	203	406	6.25 5.0	7.0 6.8	11.08 10.7	14.1 13.5	22 21
250	10	273 267.3	254	508	10.08 9.7	11.2 10.0	17.6 16.0	24.6 23.0	44.8 40.0
300	12	325 323.9 318.5	305	610	14.8	16.7	23.3	37	64.5
350	14	377 355.6	356	711	19.1 15.6	22 19.5	38 34	48.6 42.6	80.0 74.0
400	18	426 406.4	406	812	29.0 26.5	35 30	57.0 49.9	67 62	149.0 135.0
500	20	529 508	508	1016	-	-	-	-	-
550	22	559	559	1118	-	-	-	-	-

Product Tags:


*From:	Your email address is incorrect!
*To:	TOBO STEEL GROUP CHINA
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Stainless Steel Elbow
Brand Name:	TOBO
Model Number:	ASTM A403 WP317L
Certification:	SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin:	CHINA
MOQ:	3PCS
Price:	Negotiation
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	9980000PCS Per Month
Delivery Time:	15DAYS
Packaging Details:	PLY-WOODEN CASE OR PALLET
Type of pipe fittings:	Short / Long Radius Elbow(90D,45D,180D)
Thickness:	SCH5-SCH 160S ,SCH XXS
Delivery Time::	15 Days
Packaging Details::	butt welding pipe fitting commonly should be shipped in wooden cases, wooden pallets or as per customers request
Material Grade:	ASTM A403 WP317L
