| Brand Name: | Tankii |
| Model Number: | J / K / T / E / N / B / R / S |
| Certification: | ISO9001 |
| Place of Origin: | China |
| MOQ: | 100 Meters |
| Price: | Negotiation |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram, |
| Supply Ability: | 1000Ton per month |
| Delivery Time: | 5-7 days |
| Packaging Details: | Standard exoprt package |
| Material: | Chromel Alumel |
| Surface: | Bright / Oxidized |
| Thickness: | no less than 0.1mm |
| Width: | 2.0-150mm |
| Item: | Annealing Surface 0.1 Mm 2.4mm Bare Thermocouple Wire Chromel Alumel Type K J T E N J |
| Company Info. |
| Shanghai Tankii Alloy Material Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Quick Description
A typical thermocouple construction consists of a pair of dissimilar metals that are electrically joined together at the sensing point and connected to a voltage measuring instrument at the other end. When one junction is hotter than the other, a thermal “electromotive” force (in millivolts) is produced that is roughly proportional to the difference in temperature between the hot and cold junctions.
The thermocouple strips / wires with different varieties and specifications of our company can be applied in all kinds of thermocouples, the temperature ranges from -270℃ to 1800℃.
The thermocouple strips / wires have excellent performance and are extensively used in the temperature measurement and control in different fields, such as metallurgy, chemical industry, petroleum industry, machinery-electric industry, energy industry, agriculture and military industry.
Our products conform to the standards of IEC584 -1and IEC-2.
Thermocouple connectors, thermocouple strips are available.
Thermocouple type and index | Measurement Range ℃ | |
Type | Index | |
PtRh30-PtRh6 | B | 600~1700 |
PtRh13-Pt | R | 0~1600 |
PtRh10-Pt | S | 0~1600 |
NiCr-NiSi | K | -200~1300 |
NiCr-CuNi (constantan) | E | -200~900 |
Fe-CuNi (constantan) | J | -40~750 |
Cu-CuNi (constantan) | T | -200~350 |
NiCrSi-NiSi | N | -200~1300 |

|
