| Categories | Stepping Motor |
|---|---|
| Place of Origin: | 57HY 57mm NEMA23 1.8°rounnd shape |
| Brand Name: | Nema |
| Model Number: | 57HY 57mm NEMA23 1.8°round shape |
| MOQ: | 1pc |
| Price: | based on the specification and quantity |
| Packaging Details: | cartons |
| Delivery Time: | according to model No and quantity |
| Payment Terms: | pay by T/T |
| Supply Ability: | 1000sets |
| Item | Specifications |
| Step Angle Accuracy | ±5% |
| Resistance Accuracy | ±10% |
| Inductance Accuracy | ±20% |
| Temperature Rise | 80℃ Max |
| Ambient Temperature | -20℃～+50℃ |
| Insulation Resistance | 100MΩMin.500VDC |
| Dielectric Strength | 500VAC for one minute |
| Shaft Radial Play | 0.02Max.(450g-load) |
| Shaft Axial Play | 0.08Max.(450g-load) |
| Model No | Step Angle (°) | Rated Voltage (V) | Rated Current (A) | Phase Resistance (Ω) | Phase Inductance (mH) | Holding Torque (Kg.cm) | Detent Torque (g.cm Max) | Rotor Inertia (g.cm²) | Motor Length (mm) | Leads No. | Motor Weight (Kg) |
| 57HY41-0406 | 1.8 | 12 | 0.4 | 30 | 30 | 2.8 | 180 | 57 | 41 | 6 | 0.54 |
| 57HY41-1504 | 1.8 | 2.85 | 1.5 | 1.9 | 4 | 3 | 180 | 57 | 41 | 4 | 0.54 |
| 57HY41-2104 | 1.8 | 1.68 | 2.1 | 0.8 | 1.4 | 3.2 | 180 | 57 | 41 | 4 | 0.54 |
| 57HY51-0426 | 1.8 | 12 | 0.42 | 29 | 36 | 5 | 350 | 110 | 51 | 6 | 0.6 |
| 57HY51-1504 | 1.8 | 3.75 | 1.5 | 2.5 | 6 | 6 | 350 | 110 | 51 | 4 | 0.6 |
| 57HY51-2004 | 1.8 | 2.6 | 2 | 1.3 | 3.2 | 6 | 350 | 110 | 51 | 4 | 0.6 |
| 57HY56-0606 | 1.8 | 12 | 0.6 | 20 | 20 | 6 | 420 | 145 | 56 | 6 | 0.65 |
| 57HY56-1206 | 1.8 | 6 | 1.2 | 5 | 6.8 | 6 | 420 | 145 | 56 | 6 | 0.65 |
| 57HY56-2804 | 1.8 | 2 | 2.8 | 0.72 | 1.8 | 8 | 420 | 145 | 56 | 4 | 0.65 |
| 57HY76-0686 | 1.8 | 12 | 0.68 | 17.7 | 30 | 9 | 720 | 200 | 76 | 6 | 0.95 |
| 57HY76-2104 | 1.8 | 4.62 | 2.1 | 2.2 | 6.2 | 11 | 720 | 230 | 76 | 4 | 0.95 |
| Above only for representative products, products of special request can be made according to the customer request. | |||||||||||
|
