| Categories | Cylindrical Roller Bearing |
|---|---|
| Brand Name: | UMT, NTN, NSK, FAG, INA, TIMKEN or OEM |
| Model Number: | NU205E |
| Certification: | ISO9001:2008, ISO/TS16949, REACH, ROHS, MSDS, CQC |
| Place of Origin: | Germany, France, Italy, Japan, Sweden, China etc. |
| MOQ: | 10pieces |
| Price: | US$ 1 - 50 / piece |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal |
| Supply Ability: | 1,000,000 pieces per month |
| Delivery Time: | 2-7 days after receiving the payments or deposit |
| Packaging Details: | original package, Netural package, single package, Wooden package+pallet, Carton package+pallet, or as customerized. |
| Type: | Roller bearing |
| Structure: | Cylindrical |
| Number of Row: | Single row |
| Seals Type: | OPEN |
| Precision Rating: | ABEC-1/ P0, ABEC-3/P6, ABEC-5/P5, ABEC-7/P4 |
| Material: | Chrome steel, Stainless steel |
| Cage: | Steel,Brass,Nylon |
| Clearance: | C2,C0,C3,C4,C5 etc. |
| Vibration: | V1,V2,V3 |
| Service: | OEM&ODM both available |
| Sample available: | Yes |
| Manufacturer: | Yes |
| ID: | 25mm |
| OD: | 52mm |
| Width: | 15mm |
NU205 E Bearings 25x52x15 mm Cylindrical roller bearing for air compressor
What is a Cylindrical Roller Bearing?
Cylindrical roller bearing are of high load capacity and can operate at high speeds because they use rollers as their rolling elements. They can therefore be used in applications involving heavy radial and impact loading.
The rollers are cylindrical in shape and crowned at the end in order to reduce the stress concentrations. They are also suitable for applications that require high speed because the rollers are guided by ribs which are either on the outer or inner ring.
| NU205 E Bearings 25x52x15 mm Cylindrical roller bearing for air compressor | |
| Model Number | NU205E |
| Structure | Cylindrical |
| Type | roller bearing |
| ID | 25mm |
| OD | 52mm |
| Width | 15mm |
| Seals Type | Z, ZZ, RS, 2RZ, 2RS,OPEN |
| Number of Row | Single Row |
| Material | Chrome steel, Stainless steel |
| Cage | Brass, Steel, Nylon |
| Vibration Level | V1, V2, V3 |
| Clearance | C2, C0, C3, C4, C5 etc. |
| Precision Rating | P0, P6, P5, P4, P2 |
| Hardness | 59-63HRC |
| Service | OEM&ODM both available |
| Sample available | Yes |
| Manufacturer | Yes |
| Quality guaranteed | Yes |
| Certificate | ISO9001:2008, ISO/TS16949 |
| Application/Function | Steel Industry, Mining&Construction, Paper making Machinery,vibrating screens, shakers, conveyors |
| Other Service | Design service, Buyer label service |
| Packaging Details | Industrial Packing, Individual Boxed Packing, or OEM |
| Delivery Detail | 2-7 days after receiving the payments or deposit |
The NU cylindrical roller bearing has double capped edges on outer ring and without capped edge on
inner ring.
The N cylindrical roller bearing has double capped edges on inner ring and without capped edge on
outer ring.
The NJ cylindrical roller bearing has double capped edge on outer ring and single capped edge on
inner ring.
The NF cylindrical roller bearing with the single capped edge on outer ring & double capped edges on inner ring.
The NUP cylindrical roller bearing with double capped edges on the outer ring & with capped edge on one side of the inner ring, as well as with inner ring loose rib on the other side of the inner ring.
The RNU cylindrical roller bearing has an outer ring with double capped edges but does not come with inner ring. Such bearing is the NU cylindrical roller bearings without the inner ring
The RN cylindrical roller bearing has an inner ring with double capped edge but does not come with outer ring
Hot-sales for your reference.
| NU1004 | NU202 | NU244 | NU338 | NU2214 | NU2320 |
| NU1005 | NU203 | NU248 | NU340 | NU2215 | NU2322 |
| NU1006 | NU204 | NU252 | NU406 | NU2216 | NU2324 |
| NU1009 | NU205 | NU260 | NU407 | NU2217 | NU2326 |
| NU1010 | NU206 | NU303 | NU408 | NU2218 | NU2328 |
| NU1011 | NU207 | NU304 | NU409 | NU2219 | NU2330 |
| NU1012 | NU208 | NU305 | NU410 | NU2220 | NU2332 |
| NU1013 | NU209 | NU306 | NU411 | NU2222 | NU2334 |
| NU1014 | NU210 | NU307 | NU412 | NU2224 | NU2336 |
| NU1018 | NU211 | NU308 | NU413 | NU2226 | NU2338 |
| NU1020 | NU212 | NU309 | NU414 | NU2228 | NU2340 |
| NU1021 | NU213 | NU310 | NU415 | NU2230 | NU2344 |
| NU1022 | NU214 | NU311 | NU416 | NU2232 | NU2372 |
Our other main products:
Deep groove ball bearing, Taper roller bearing, Ceramic ball
bearing, Cylindrical roller bearing, Spherical roller bearing,
Self-aligning bearing, Adapter sleeve, Angular contact ball
bearing, Thrust ball bearing, Thrust roller bearing, Needle roller
bearing, Spherical plain bearings, Linear bearing, Whell hub
bearing, Special bearing
Shenzhen Youmeite Berings CO., ltd is branch company of shandong UMT bearing corporation responsible
for oversea marketing. Our plant shandong UMT has been working in
the filed of bearing design and manufacturing for more than 10years now is taking a leading position in mainland china. Our plant has
more than 500 employees , including 30 bearing professional techincians; more than 600 new bearing items can be completed each year. we can produce all kinds of bearing as
customer's requirement.
