Triple Integrated Circuit Chip 2 Channel Analog Multiplexer / Demultiplexer HCF4053B

HCF4053B

TRIPLE 2-CHANNEL

ANALOG MULTIPLEXER/DEMULTIPLEXER

■ LOW "ON" RESISTANCE : 125Ω (Typ.) OVER 15V p.p SIGNAL-INPUT RANGE FOR VDD - VEE = 15V

■ HIGH "OFF" RESISTANCE : CHANNEL LEAKAGE ± 100pA (Typ.) at VDD - VEE = 18V

■ BINARY ADDRESS DECODING ON CHIP

■ HIGH DEGREE OF LINEARITY : < 0.5% DISTORTION TYP. at fIS = 1KHz, VIS =5Vpp, VDD - VSS > 10V, RL = 10KΩ

■ VERY LOW QUIESCENT POWER DISSIPATION UNDER ALL DIGITAL CONTROL INPUT AND SUPPLY CONDITIONS : 0.2 µW (Typ.) at VDD - VSS = VDD - VEE =10V

■ MATCHED SWITCH CHARACTERISTICS : RON = 5Ω (Typ.) FOR VDD - VEE = 15V

■ WIDE RANGE OF DIGITAL AND ANALOG SIGNAL LEVELS : DIGITAL 3 to 20, ANALOG TO 20V p.p.

■ QUIESCENT CURRENT SPECIF. UP TO 20V

■ 5V, 10V AND 15V PARAMETRIC RATINGS

■ INPUT LEAKAGE CURRENT II = 100nA (MAX) AT VDD = 18V TA = 25°C

■ 100% TESTED FOR QUIESCENT CURRENT

■ MEETS ALL REQUIREMENTS OF JEDEC JESD13B " STANDARD SPECIFICATIONS FOR DESCRIPTION OF B SERIES CMOS DEVICES"

DESCRIPTION

The HCF4053B is a monolithic integrated circuit fabricated in Metal Oxide Semiconductor. technology available in DIP and SOP packages. The HCF4053B analog multiplexer/demultiplexer is a digitally controlled analog switch having low ON impedance and very low OFF leakage current. This multiplexer circuit dissipate extremely low quiescent power over the full VDD - VSS and VDD - VEE supply voltage range, independent of the logic state of the control signals. When a logic "1" is present at the inhibit input terminal all channel are off. This device is a triple 2-channel multiplexer having three separate digital control inputs, A, B, and C, and an inhibit input. Each control input selects one of a pair of channels which are connected in a single pole double-throw configuration.

SPECIAL CONSIDERATIONS

Control of analog signals up to 20V peak to peak can be achieved by digital signal amplitudes of 4.5 to 20V (if VDD - VSS = 3V, a VDD - VEE of up to 13V can be controlled; for VDD - VEE level differences above 13V, a VDD - VSS of at least 4.5V is required. For example, if VDD = +5, VSS = 0, and VEE = -13.5, analog signals from -13.5V to 4.5V can be controlled by digital inputs of 0 to 4.5V. In certain applications, the external load resistor current may include both VDD and signal-line components. To avoid drawing VDD current when switch current flows into the transmission gate inputs, the voltage drop across the bidirectional switch must not exceed 0,8V (calculated from RON values shown in DC SPECIFICATIONS). No VDD current will flow through RL if the switch current flows into leads 4, 14 and 15.
