| Categories | Thermocouple Compensating Cable |
|---|---|
| Certification: | ISO9001,CCC,CE,IEC,BV,SGS |
| Place of Origin: | Wuhan, China |
| MOQ: | 1000m |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000m/month |
| Delivery Time: | 5-8 days after payment |
| Packaging Details: | packing for export |
| Price: | Negotiable |
| Insulation Material: | silicone rubber |
| Conductor Material: | copper or tinned copper |
| Type: | Low Voltage |
| Jacket: | silicone rubber |
| Application: | Industrial |
| Certificate: | ISO9001,CCC,CE,IEC,BV,SGS |
| Company Info. |
| Wuhan Global Metal Engineering Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Type K(CHROMEL vs ALUMEL) is used in oxidizing, insert or dry reducing atmospheres.Exposure to Vacuum limited to short time periods. Must be protected from sulfurous and marginally oxidizing atmospheres.Reliable and accurate at high temperatures.
| thermocouple compensation cable | |
| Grade: | Extension Grade or Thermocuple Grade |
| temperature range, deg. c | -50 to +400 |
| type of coductor: | K, J, T, E, N, S, R, KX, JX, TX, EX, NX, SX, RX |
| number of conductors: | 1,2,3,4,6 |
| Conductor type | Strand or Solid |
| material of insulation: | fiberglass, telfon, PTFE, PVC, silicone,so on |
| material of jacket: | fiberglass, telfon, PTFE, PVC, silicone,so on |
| shielding material: | Stainless Steel Braid and Tinned Copper wire braid |
| Thermocouple Extension Wire Compensating Cable | ||||||
Type of Compensating Conductor | Equipped Thermocouple | Thermocouple Index | Compensating Conductor Allong-wire | Insulation Layer Coloration | ||
| Positive | Negative | Positive | Negative | |||
| SC | PtRh10-Platinum thermocouple10 | S | SPC Cu | SNC | Red | Green |
| Cu Ni | ||||||
| RC | PtRh13-Platinum thermocouple13 | R | RPC Cu | RNC Cu Ni | Red | Green |
| KCA/KCB/KX | Ni Cr- Nisi-loy Thermocouple | K | KPCA Fe/ | KNCA Cu Ni/ | Red | Blue/ |
| KPCB Cu/ | KNCB Cu Ni/ | Blue/ | ||||
| KPX Ni Cr | KNX Ni Si | Black | ||||
| NC/NX | Ni Cr- Nisi-loy Thermocouple | N | NPC Fe | NNC Cu Ni | Red | Grey |
| NPX | NNX Ni Si | Grey | ||||
| Ni Cr Si | ||||||
| EX | Ni Cr- Copper-nickel Thermocouple | E | EPX Ni Cr | ENX Cu Ni | Red | Brown |
| JX | Fe- Copper-nickel Thermocouple | J | JPX Fe | JNX Cu Ni | Red | Purple |
| TX | Cu- Copper-nickel | T | TPX Cu | TNX Cu Ni | Red | White |
| Thermocouple | ||||||
|
