1.4429-ESU 316LN Stainless Steel Round Bar Hot Rolled / Cold Roleld Round Bar

1.4429-ESU 316LN Stainless Steel Round Bar Hot Rolled / Cold Roleld Round Bar

1.4429-ESU 316LN Stainless Steel Round Bar Hot Rolled / Cold Roleld Round Bar
1.4429-ESU 316LN Stainless Steel Round Bar Hot Rolled / Cold Roleld Round Bar
Categories Stainless Steel Round Bar
Brand Name: TISCO BAO STEEL
Model Number: 316LN
Certification: SGS
Place of Origin: China
MOQ: 1 tons
Price: 6350 usd/ton
Payment Terms: L/C, T/T
Supply Ability: 500 tons
Delivery Time: 7 days
Packaging Details: export packing
OD: 3-450mm
Length: 2000-6000mm
Surface: Black and Bright
Type: Hot Rolled and Cold Roleld
Contact Now
Company Info.
JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1.4429-ESU 316LN Stainless Steel Round Bar Hot Rolled / Cold Roleld Round Bar


Material 1.4429-ESU (316LN) According to CERN Specification 316L Stainless Steel Round Bar


ASTM A240/A240M AISI 316LN DIN 1.4429 Stainless Steel Plate 2B and NO.1 Finish

316LN (UNS S31653) is a lowcarbon, nitrogen-enhanced version of Type 316 molybdenum-bearing austenitic stainless steel. The Type 316 alloys are more resistant to general corrosion and pitting/crevice corrosion than the conventional chromium-nickel austenitic stainless steels such as Type 304. They also offer higher creep, stress-rupture and tensile strength at elevated temperature. The nitrogen in Type 316LN adds additional resistance to sensitization in some circumstances.

The nitrogen content of Type 316LN stainless steel also provides some solid solution hardening, raising its minimum specified yield strength compared to Type 316L stainless steel. Like Types 316 and 316L, the Type 316LN alloy also offers good resistance to general corrosion and pitting/crevice corrosion.

Available tube product forms

TECHNICAL DATA

Mechanical Properties

TemperAnnealedCold worked
Tensile Rm75ksi (min)125ksi (min)
Tensile Rm515MPa (min)860MPa (min)
R.p. 0.2% Yield30ksi (min)100ksi (min)
R.p. 0.2% Yield205MPa (min)690MPa (min)
Elongation (2" or 4D gl)35% (min)15% (min)


Physical Properties (Room Temperature)

Specific Heat (0-100°C)485J.kg-1.°K-1
Thermal Conductivity16.3W.m -1.°K-1
Thermal Expansion16.5mm/m/°C
Modulus Elasticity200GPa
Electrical Resistivity7.4μohm/cm
Density7.99g/cm3

Chemical Composition (% by weight)

ElementMinMax
C-0.03
Mn-2
Ni1315
Cr1719
Mo23
S-0.1
Si-0.75
P-0.25

AISI 316LN is developed for enhanced creep resistance and for higher strength at temperatures above 1000°F (537°C). In most instances, the carbon content of the plate enables dual
AISI 316LN is a difficult to shape and machine using traditional techniques due to rapid work hardening.
Due to special mechanical properties of AISI 316LN forging parts, there are many wide uses as followings:
AISI 316LN seamless rolled rings and AISI 316LN forging shafts that is used in Nuclear, chemical processing, Rubber, plastics, pulp/paper, pharmaceutical and textile industries, heat exchangers, condensers and evaporators
AISI 316LN forged shafts,AISI 316LN forging pipes, AISI 316LN forged tubes ,forged tube sheets, forged flanges that are used in pressure vessel ,air receivers,Shell & Tube Heat Exchangers
AISI 316LN forging shafts,AISI 316LN forging flanges ,AISI 316LN forged rings,AISI 316LN forging pipes that is used inColumns & Towers,Tanks ,Silos,Process Modules,Preheaters
AISI 316LN forging pieces,AISI 316LN forged sleeves,AISI 316LN forged disks,AISI 316LN forged discs that is used in Offshore and onshore industry, such as subsea and deepwater offshore oil production systems, industrial air compressors, power generators and nitrogen generators
AISI 316LN open die forging parts,forging pieces,forging nozzles forged crankshaft that is used in Petroleum Refining fluid catalytic cracking units, polythionic acid service
AISI 316LN forged valve stems, forged valve parts, forged valve seat ring,forged valve blocks,forged bodies that are used in ball valves, check valves, strainers ,globe valve, gate valve,Plug valve and so on
AISI 316LN forging rings, AISI 316LN forging spindles, AISI 316LN forging bars,AISI 316LN forging gears that are used in power transmission, turbine,gas compressor,gear boxes and so on
AISI 316LN forged products,AISI 316LN forged nozzles,AISI 316LN forging eccentric shaft that are used on processing units,mechanical equipment, crystalizer equipment,Wellhead and Christmas tree
AISI 316LN forged wheels, forged manifold, forged eccentric shaft that are used in Pharmaceutical Production,Waste Heat Recovery,recuperators
Our AISI 316LN forged parts will be Ultrasonic testing as per standard, EN10228-3,Sep1921,ASTM A388 and so on
We could supply AISI 316LN super allloy forging parts certificate as per the standard of EN10204-3.1 or EN10204-3.2 of third party
Please send us the size or drawing of AISI 316LN forged material that you need, we are glad to quote the best price for your side
