| Categories | Pcb Board Fuse |
|---|---|
| Brand Name: | Julun |
| Model Number: | 438GT |
| Certification: | CE/UL/VDE/KC/ROHS |
| Place of Origin: | CHINA |
| MOQ: | 100 / Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C, D/P, T/T, |
| Supply Ability: | 10000/Piece/Weekly |
| Delivery Time: | 7~10 Working days |
| Packaging Details: | Standard carton |
| Decoupling ability: | Fast |
| Current range: | 2A~6A |
| Material: | Ceramics |
| Rated voltage: | 32V |
| Certified: | UL / PSE |
| Company Info. |
| JULUN (H.K)CO.,LTD (DONGGUAN JULUN ELECTRONICS CO.,LTD) |
| Verified Supplier |
| View Contact Details |
| Product List |
Fast Acting Ceramic Electronic Circuit Board Fuses 32V High Surge Current Protection
The 438GT Series is a 100% Lead-free, RoHS compliant and Halogen-free fuse series designed specifically to provide over-current protection to circuits that operate under high working ambient temperature up to 150ºC. The general design ensures excellent temperature stability and performance reliability.
Features
• Operating Temperature from -55ºC to +150ºC
• 100% Lead-free, RoHS compliant and Halogen-free
• Suitable for both leaded and lead-free reflow/ wave soldering
Applications
• Handheld Electronics • LCD Displays • Battery Packs • Hard Disk Drives • SD Memory Cards
| % of Ampere Rating | Ampere Rating | Opening Time |
| 100% | 2A – 6A | 4 hours, Minimum |
| 250% | 2A – 6A | 5 Seconds, Maximum |
| Ampere Rating | Amp Code | Max.Voltage Rating | Interrupting Rating | Nominal Resistance | Nominal Melting I2t | Nominal Voltage Drop At Rated Current | Nominal Power Dissipation At Rated Current |
| 2 | 2 | 32 | 50A @ 32VDC/12VAC | 0.049 | 0.181 | 0.11 | 0.22 |
| 2.5 | 2.5 | 32 | 0.0364 | 0.24 | 0.094 | 0.235 | |
| 3 | 3 | 32 | 0.0264 | 0.439 | 0.082 | 0.246 | |
| 3.5 | 3.5 | 32 | 0.021 | 0.647 | 0.078 | 0.273 | |
| 4 | 4 | 32 | 0.0164 | 0.739 | 0.075 | 0.3 | |
| 5 | 5 | 32 | 0.0127 | 0.747 | 0.072 | 0.36 | |
| 6 | 6 | 24 | 50A @ 24VDC/12VAC | 0.0086 | 1.444 | 0.07 | 0.42 |
