| Categories | Tianma LCD Displays |
|---|---|
| Brand Name: | Tianma |
| Model Number: | TM035KBZ12 |
| Certification: | ISO9001 |
| Place of Origin: | KOREA |
| MOQ: | 1 Piece |
| Payment Terms: | T/T, Paypal, Western Union, MoneyGram |
| Supply Ability: | 100 PCS / DAY |
| Delivery Time: | 2-3 working days after payment confirmation |
| Packaging Details: | Antistatic bag, Bubble Bag, Foam Box and Carton Box. |
| Panel Brand: | TIANMA |
| Panel size: | 3.5 inch |
| Screen Type: | LCM, a-Si TFT-LCD |
| Good View at: | 12 o'clock |
| Mass: | TBD |
| Refresh Rate: | 60Hz |
| Company Info. |
| N&S ELECTRONIC CO., LIMITED |
| View Contact Details |
| Product List |
TM035KBZ12 Information
| Panel Model | TM035KBZ12 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 70.08×52.56 mm |
| Outline | 76.9×63.9×4.3 mm |
| Contrast Ratio | 350:1 (Typ.) |
| Display Colors | 16.7M (8-bit) , CIE1931 50% |
| Response Time | 25/25 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/60 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1P WLED Without Driver |
| Signal Interface | Digital RGB (8/24-bit) + SPI, CCIR601/656 , 54 pins |
| Input Voltage | 3.3V (Typ.) |
Our Promise for our LCD Panels:
You will get reply within 24 Hours and:
Year warranty
Day shipping
Return
<
TM035KBZ12 Basic Information
| Panel Model | TM035KBZ12 |
|---|---|
| Panel Brand | TIANMA |
| Descrition | a-Si TFT-LCD ,3.5 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Remarks | 3 in 1 FPC |
| Dot Resolution | 320(RGB)×240 (QVGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 115 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.073×0.219 mm (H×V) |
| Pixel Pitch | 0.219×0.219 mm (H×V) |
| Weight | TBD |
| Active Area | 70.08×52.56 mm (H×V) |
| Bezel Area | 72.08×54.56 mm (H×V) |
| Outline Dimension | 76.9×63.9 mm (H×V) |
| Outline Depth | 4.0±0.3 mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Embeded (4-wire Resistive, Film / Glass) |
