Brief Introduction - Railroad electric trailer dolly

Railroad electric trailer dolly are battery powered. It can be used both on the “S” and arc-shaped railways. The KPX series are more safe and flexible and running distance is not limited. It has no strict requirement for the construction of the railway. Motorized transfer trolley is suitable to be used in the long distance transportation, and it is a great solution of industry heavy materials handling.

Advantages - Railroad electric trailer dolly

• Box girder, two longitudinal girder and several beams, not easy to deform
• Convenient loading and unloading: forklift hole and hoisting hole for convenient loading and unloading on the port and client site
• Proetction device: Steel plate to protect the electrical box
• For convenient to replace the battery, we design the push pull battery installation way

Working principle - Railroad electric trailer dolly

KPX SeriesRailroad electric trailer dolly are battery powered. The battery are installed in the carts. The battery supplies electricity to the DC motor through the electrical control system. We use this principle to make the car start, stop, move forward, move backward, adjust the speed etc.

Application - Railroad electric trailer dolly

Railroad electric trailer dolly is applied to transfer steel ladles or steel scrap ladle in steel factory and meturallgy plant. Generally the load capacity is large, can reach to 150 tons. It is commonly applied in steel plant, mechallurgy industry, aluminum factory, plastic pipes factory, etc. to transfer rounded material, from producing line to store.

Parameters - Railroad electric trailer dolly

Model		KPX-2T	KPX-10T	KPX-20T	KPX-30T	KPX-50T	KPJ-63T	KPX-150T
Rated load (T)		2	10	20	30	50	63	150
Table size	length(L)	2000	3600	4000	4500	5500	5600	10000
	Width(W)	1500	2000	2200	2200	2500	2500	3000
	Height(H)	450	500	550	600	650	700	1200
Wheel Base (mm)		1200	2600	2800	3200	4200	4300	7000
Rail Inner Gauge (mm)		1200	1435	1435	1435	1435	1435	2000
Wheel Diameter(mm)		Φ270	Φ300	Φ350	Φ400	Φ500	Φ600	Φ600
Wheel Quantity		4	4	4	4	4	4	8
Ground Clearance (mm)		50	50	50	50	50	75	75
Running speed (min)		0-25	0-25	0-20	0-20	0-20	0-20	0-18
Motor Power (Kw)		1	1.6	2.2	3.5	5	6.3	15
Battery Capacity(Ah)		180	160	180	250	330	400	600
Battery Voltage(V)		24	48	48	48	48	48	72
Running Time When Full Load		4.32	4.8	4	3.5	3.3	3	2.9
Running Distance for one Charge(Km)		6.5	7.2	4.8	4.2	4	3.6	3.2
Max Wheel Load (KN)		14.4	42.6	77.7	110.4	174	221.4	265.2
Reference Weight (t)		2.8	4.2	5.9	6.8	8	10.8	26.8
Recommended Rail Model		P15	P18	P24	P38	P43	P50	QU100

Packing & Delivery - Railroad electric trailer dolly

The 4 wheel electric car will be packed by the tarp, the parts will be packed by polywood case.

Client feedback

Company glance

Xinxiang New Leader Machinery Manufacturing Co., Ltd is devoted to manufacture and sell lifting and material handling equipment with 15 years experience. NEWLD is a professional and international handling equipment company integrating R&D, design, production and sales. It has a modern management team, technical team and production technician team.

Our company is located in Xinxiang city, Henan province, covering an area of 33,300 square meters. It has a modern large-scale factory building, world-advanced production equipment and office equipment. The company has more than 150 employees, including 8 engineers and more than 20 technicians. The company has a first-class research and design team, which can undertake the design and production of various non-standard handling equipment.

NEWLD can not only provide transfer cart quotations, but also provide you with satisfactory handling solutions.

We can produce 1-1500 ton range of various tonnage of AGV, RGV, rail transfer cart, trackless transfer cart, flatbed trailer, towing tractor, locomotive turntable, industrial turntable and so on with more than 90 products. Customized all kinds of function required, such as turning, lifting, tilting, climbing, roller, anti-high temperature, anti-explosion, etc.. Newld also can provide transfer cart parts, including rail wheel, rail and rail accessories, industrial winch and so on.

Our products have a wide application field including metallurgy industry, machinery manufacturing industry, steel mill, mine industry, power industry, mold industry, automobile assembly industry, shipyard industry etc.

Our product has been exported to more than 90 countries and regions, such as Indonesia, America, Russia, Brazil, United Arab Emirates, Pakistan, Middle East, Saudi Arabia, Bangladesh, Philippines, Canada, Azerbaijani, Kuwait, Dubai, Egypt, Nepal, Vietnam, Laos, Myanmar, Germany, etc.
