| Categories | Flat Plate Solar Collector |
|---|---|
| Brand Name: | PASSION/OEM |
| Model Number: | 2 sqm |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000units/month |
| Delivery Time: | 10 working days |
| Packaging Details: | CARTONS/PLYWOOD CASE/PALLET |
| Seal Material: | EPDM |
| Dimension of End pipe: | φ22 ×δ0.6mm |
| Use: | Residential Water Heating |
| Header Material: | Copper TP2 |
| Insulation: | Glass wool |
| Frame Colour: | Silver |
| Absorber coating: | Blue Titanium |
| Mouting: | Aluminum alloy |
| Company Info. |
| JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
Fashion Designs Thermal Concentrated Flat Panel Collectors Residential Water Heating
Feature of Flat Plate collector
1. using patent advanced coating technology with high efficiency performance.
2. High strength aluminum-alloy structure with surface varnish baking.
3. High visual shape, easy installation, maintenance free.
4. Pressurized designing, operate with pressure up to 1 MPa.
5. Can be combined with existing energy.
Features
Copper pipes and fins
Blue Vacuum Coating
American ultrasonic welding
Tempered glass cover
Size: 2000*1000*90mm
Advantages
Great pressurization property, very safe and clean.
Absorption ≥95%; emission ≤5%.
Strong thermal stability.
Strong welding property and conductivity.
Strong protection to the collector.
Benefits
Durable and corrosion-resistant material makes your maintenance cost low.
Comfortable hot water can be gained even in medium solar radiation areas.
Increases the value of your property.
Long lifespan to 25 years, makes your investment more worth it.
Worry-free from hails or other terrible weathers.
Specification
| Model No. | PT-C01 | PT-A02 | PT-B02 | PT-C02 |
| Dimension L×W×T(mm) | 2000×1000×70 | 2000×1000×80 | 2000×1000×90 | 2000×1000×100 |
| Gross Area(m2) | 2 | 2 | 2 | 2 |
| Efficiency Area (m2) | 1.82 | 1.82 | 1.82 | 1.82 |
| Gross Weight of Collector(kg) | 47±3 | 55 ±3 | 47 ±3 | 55 ±3 |
| Transparent Cover | ||||
| Number of Cover(pc) | 1 | 1 | 1 | 1 |
| Dimension L×W(mm) | 1975 × 975 | 1975 × 975 | 1975 × 975 | 1975 × 975 |
| Cover Material | Float Glass / Low-iron Glass | Float Glass / Low-iron Glass | Float Glass / Low-iron Glass | Float Glass / Low-iron Glass |
| Cover Thickness(mm) | 3.2 | 3.2 | 3.2 | 3.2 |
| Cover Transmission | 91% | 91% | 91% | 91% |
| Absorber | ||||
| Dimension L×W(mm) | 1840 × 956 | 1840 × 956 | 1840 × 956 | 1840 × 956 |
| Material | Red Copper | Red Copper | Red Copper | Red Copper |
| Surface Treatment | Black Chrome | Blue Titanium | Black Chrome | Blue Titanium |
| Construction Type | Fin and Tube | Fin and Tube (Ultrasonic Welding) | Fin and Tube | Fin and Tube |
| Header Material | T2 Copper | Copper TP2 | T2 Copper | Copper TP2 |
| Header Tube Size(mm) | Φ25 × 1060 × 0.6 × 2pcs | Φ25 × 1060 × 0.6 × 2pcs | Φ25 × 1060 × 0.6 × 2pcs | Φ25 × 1060 × 0.6 × 2pcs |
| Rise Material | T2 Copper | Copper TP2 | T2 Copper | Copper TP2 |
| Rise Tube Size(mm) | Φ10 × 1886 × 0.5 × 8pcs | Φ10 × 1886 × 0.5 × 8pcs | Φ10 × 1886 × 0.5 × 8pcs | Φ10 × 1886 × 0.5 × 8pcs |
| Fill Capacity | 1.8L Including Header Pipe | 1.8L Including Header Pipe | 1.6L Including Header Pipe | 1.8L Including Header Pipe |
| Thermal Insulation | ||||
| Insulation Material | Rook Wool (back) | Rook Wool (back) | Rook Wool (back) | Rook Wool (back) |
| Polyurethane(side) | Polyurethane(side) | Polyurethane(side) | Polyurethane(side) | |
| Insulation Thickness | 40mm(back)/25mm(side) | 50mm(back)/30mm(side) | 40mm(back)/25mm(side) | 50mm(back)/30mm(side) |
| Conductivity(W/mK) | ≤0.032 under 75°c | ≤0.042 under 75°c | ≤0.032 under 75°c | ≤0.032 under 75°c |
| Casing | ||||
| Frame | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy |
| Frame Color | Bronze color | Bronze color | Bronze color | Bronze color |
| Back Plate | 0.3mm Galvanized Steel | 0.3mm Galvanized Steel | 0.5mm Galvanized Steel | 0.5mm Galvanized Steel |
| Max Operation Temperature | 180°c | 200°c | 180°c | 200°c |
| Maximum Pressure(Mpa) | 0.6 | 1.4 | 0.6 | 1.4 |
| Sealing Gasket | EPDM | EPDM | EPDM | EPDM |
| Limitation of Operation | ||||
| Max.Working Temperature | 120°c | 120°c | 120°c | 120°c |
| Max.Working Pressure | 0.5Mpa | 1.2Mpa | 0.5Mpa | 1.2Mpa |
| Recommended Circulation Flow | Water | Propylene glycol&water mixture | Water | Propylene glycol&water mixture |
| Resistance to Freezing | ≥0°c | ≥-40°c | ≥0°c | |
Packaging & Shipping
Packaging Details: Export strong corrugated carton.
Delivery Detail: Within 7 - 10 days for container order quantity upon confirmed invoice or sales contract.
Warranty
10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.
Basic trade term & packages
MOQ: 20'GP container (Sample is available)
Warranty: 10 years guarantee for whole set solar water heater
Payment term: 30% deposit by TT, Balance for BL by TT or LC
Delivery time: 7-15 days after confirmed
Port of departure: Shanghai or Ningbo
Supply ability: 8000 sets per month
Package: Standard export cartons
Quality Guarantee
We provide 5years warranty of products and shipment with 1% spare parts.
We can send the parts free on condition that there is any breakdown with convincing evidence.
1% spare parts include:
Wiper scraper seal
Tube holder
Screws & screw caps
|
