Assurance Horizontal Wood Treatment Plant High Pressure CCA ACQ With Filter

High Configuration Wood Treatment Plant Passed Government Test With Filter

Ⅰ Product description

Wood treatment plant mainly used for deep processing of wood, vacuum pressure treatment method, so the wood to achieve anti-corrosion, pest control, and other purposes. This wood treatment plant applied to various water-soluble chemicals such as CCA, ACQ, boric acid, Tanalith E and etc.

We have a large number of sucess case and shipping pictures and have exported to many countries, like Philippines, Uganda, Zambia, Kenya, Switzerland,Thailand, South Korea, Tanzania, Myanmar, Russia, Indonesia and ect.

Ⅱ Main Model

Note: The diameter and length can be customized according to users' needs. If the above model is not suitable, please tell us the diameter and length you need. We can customize it for you.

Ⅲ Technical parameters

Design pressure:1.58MPA

Operation pressure:1.0-1.4MPA

Voltage: 380V

Operation medium: various water-soluble chemicals like CCA ACQ

Material:Q345R carbon steel

Vacuum operation:-0.098MPA

Ⅳ Technology Process

Extract Vacuum---holding vacuum and adding medicament---open the pressurizing pump after reaching the liquid level ---maintain the required pressure to infuse the medicament into the wood cells for a period of time—pressure unloading—discharge Reagents --- Vacuum again --- Restoring atmospheric pressure --- Open the tank door and remove the wood --- Complete

ⅤOur advantages

1.-- The material of this machine is Q345R steel, is the special steel plate for pressure vessel, we purchase from famous Jinan steel factory.

2. -- Our company has own special flaw detection to ensure the quality of products.

3. -- Manual quick open door way, advanced open door method, only one young girl can open the door easily. Double safety device, automatic safety interlocking device and Manual safety interlocking device, it solved the safety problem of wrong operation.

4.-- Our machines are equipped with a filtration system that filters out impurities.

5. -- We have special sewage outlets to prevent the residual chemicals flowing out, will not pollute the factory floor.

Since 2008， Luy Machinery Equipment CO., LTD have more than 10 years experience in pressure vessel, the company covers an area of 5300m2 and has more than 200 employees. It is a modern new-type equipment manufacturing enterprise integrating design, manufacture and sales.

Our main products are wood impregnation equipment, cerosote wood treatment plant, wood heat treatment plant, rubber curing autoclave, composite autoclave, wood drying machine and ect. All equipments can be customized according to the customer's product process requirements, to the maximum satisfaction of different products technical and process requirements for the product.

We have exported to many countries, like Philippines, Uganda, Zambia, Kenya, Switzerland,Thailand, South Korea, Tanzania, Myanmar, Russia, Indonesia and ect.
