| Categories | Copper Nickel Alloy Wire |
|---|---|
| Brand Name: | Tankii |
| Model Number: | 0cr13al4,alloy 750 stablohm 750,0cr23al5,0cr25al5,, 0cr15al5, 0cr20al5,0cr21al6 |
| Certification: | ISO RoHS AISI ASTM GB |
| Place of Origin: | Chian |
| MOQ: | 20Kg |
| Price: | USD 20/Kg |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200Tons/Month |
| Delivery Time: | 10-15 woking days |
| Packaging Details: | Wooden Pallet, Wooden Case, Spool |
| Packing: | Case |
| Craft: | Cold Rolled |
| Characteristics: | High Resistivity, Good Oxidation Resistance |
| Sample: | Free |
| Shape: | Strip/Wire/Ribbon/Pipe/Sheet/Bar/Foil |
| Surface: | Bright |
| The Highest Use Temperature: | 200c |
| Density: | 8.9 |
| Resisivity: | 0.1 |
| Company Info. |
| Shanghai Tankii Alloy Material Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
| Characteristic | Resistivity ( 200C μΩ.m) | Max.working Temperature ( 0C) | Tensile Strength (Mpa) | Melting point (0C) | Density ( g/cm3) | TCR x10-6/ 0C (20~600 0C) | EMF vs Cu (μV/ 0C) (0~100 0C) |
| Alloy Nomenclature | |||||||
| NC020(CuNi14) | 0.2 | 300 | ≥310 | 1115 | 8.9 | <30 | -28 |
| Ni | Mn | Fe | Si | Cu | Other | ROHS Directive | |||
| Cd | Pb | Hg | Cr | ||||||
| 10 | 0.3 | - | - | Bal | - | ND | ND | ND | ND |
| Max Continuous Service Temp | 250ºC |
| Resisivity at 20ºC | 0.15±5%ohm mm2/m |
| Density | 8.9 g/cm3 |
| Thermal Conductivity | 50 (Max) |
| Melting Point | 1100ºC |
| Tensile Strength,N/mm2 Annealed,Soft | 210~370 Mpa |
| Tensile Strength,N/mm2 Cold Rolled | 420~740 Mpa |
| Elongation(anneal) | 25%(Min) |
| Elongation(cold rolled) | 2% (Min) |
| EMF vs Cu, μV/ºC (0~100ºC) | -25 |
| Micrographic Structure | austenite |
| Magnetic Property | Non |
Mechanical Properties
| Type | Electrical resistivity (20degreeΩ mm²/m) | temperature coefficient of resistance (10^6/degree) | Dens ity g/mm² | Max. temperature (°c) | Melting point (°c) |
| CuNi1 | 0.03 | <1000 | 8.9 | / | 1085 |
| CuNi2 | 0.05 | <1200 | 8.9 | 200 | 1090 |
| CuNi6 | 0.10 | <600 | 8.9 | 220 | 1095 |
| CuNi8 | 0.12 | <570 | 8.9 | 250 | 1097 |
| CuNi10 | 0.15 | <500 | 8.9 | 250 | 1100 |
| CuNi14 | 0.20 | <380 | 8.9 | 300 | 1115 |
| CuNi19 | 0.25 | <250 | 8.9 | 300 | 1135 |
| CuNi23 | 0.30 | <160 | 8.9 | 300 | 1150 |
| CuNi30 | 0.35 | <100 | 8.9 | 350 | 1170 |
| CuNi34 | 0.40 | -0 | 8.9 | 350 | 1180 |
| CuNi40 | 0.48 | ±40 | 8.9 | 400 | 1280 |
| CuNi44 | 0.49 | <-6 | 8.9 | 400 | 1280 |
|
