Membrane Chemical Air Operated Diaphragm Pump No Electricity For Pigment

Air Powered 2 Diaphragm Pump , Membrane Pump For Chemical


Air diaphragm pump(also know as a Membrane pump, air operated double diaphragm pump(AOOD) or pneumatic diaphragm pump)that uses a combination of the reciprocating action of a rubber,thermoplastic or diaphragm and suitable valves either side of the diaphragm (check valve,butterfly valves,flap valves,or any other form of shut-off valves) to pump a fluid.

Diaphragm pump description

1, No electricity. It's safe and reliable while in the flammable and explore places.

2, Pump has no rotary parts and bearing seals. The diaphragm will completely separate the exhausted medium and pump running parts, working medium. There's no leakage, thus it doesn't cause environmental pollution and human body safety dangerous while exhausting the toxin and flammable or corrosive medium.

3, It's convenient to use and reliable to work. This pump is simple in structure and easy to be installed and maintained.

The medium conveyed doesn't touch the matched pneumatic valve and coupling lever etc. While normal pumps' performance will be decreased gradually because of the damages of driving parts.

4, This pump doesn't need oil lubricant, even works in dry run.

Specifications

Air Diaphragm Pump
1. Non leakage
2. Good self priming performance
3. Convey all kinds of medium
4. Material:Cast steel,Alu,SS,PP


A 2 5 X X - X X X - X (model selection)

Form of pipe mouth:A-BSP B-NPT(F) C-Flange
Diaphragm material:9 – Santoprene H – Hytrel T - PTFE/Santoprene
Ball material:9 -Santoprene H – Hytre T – PTFE A - Acetal
Ball seat material:P/K –Polypropylene/Kynoar SS –Stainless Steel
Pump material: SS –Stainless Steel AL –Aluminum Alloy CI- Carbon Steel P/K –Polypropylene/Kynoar

Product Usage
1. Pump peanut butter, kimchi, mashed potatoes, small red sausage, jam apple pulp, chocolate, etc.
2. Pumping paint, gum, and pigment.
3, adhesives and glue, all types can be pumped.
4, a variety of tiles, porcelain, bricks and pottery glaze.
5. After the oil well is drilled, pump the sediment and grout.
6. Pump various emulsions and fillers.
7. Pumping all kinds of age.
8. Use the pump as the tanker, and the barge clears the tank to absorb the age.
9, hops and fermented powder slurry, syrup, sugar dense.
10. Pumping water from mines, tunnels, tunnels, beneficiation, and slag. Pumping cement grout and mortar.
11, a variety of rubber pulp.
12. Various abrasives, corrosives, petroleum and mud, cleaning grease and general containers.
13, a variety of highly toxic, flammable, volatile liquids.
14, a variety of strong acid, alkali, strong corrosive liquid.
15, a variety of high temperature liquids
16. As a pre-stage pressure supply device for various solid-liquid separation devices

Maximum Applied Temperature Limits (diaphragm / ball / seal material)


Acetal ··············································· 40°- 150°F (4.4- 65.5°C)
Santoprene········································· -40°- 225°F (-40°- 107.2°C) ··················································40°- 220°F (4.4°- 104°C) Nitrile···················································10°- 180°F (-12°- 82°C) Viton····················································-40°- 350°F (-40°-176.6°C) Hytrel····················································-20°-150°F (-12°- 93°C) Kynar·····················································10°-200°F (-28.9°- 65.5°C) Polypropylene··········································32°- 175°F (0-79.4°C)


1” Flow diagram
