| Categories | Stainless Steel Tube |
|---|---|
| Brand Name: | TORICH |
| Model Number: | ASTM A269 SUS304 |
| Certification: | ISO9001, ISO14001, TS16949 |
| Place of Origin: | ZHEJIANG, CHINA |
| MOQ: | 5Tons |
| Price: | negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000Tons per Year |
| Delivery Time: | 30-45 work days |
| Packaging Details: | Stainless Steel Tubes are packed in wooden boxes in seaworthy packing. |
| Keyword: | Stainless Steel Tube |
| Material: | SUS304 |
| OD: | 15.88mm-203.2mm |
| WT: | 0.5mm-6.5mm |
| Length: | Customers' Requirements |
| Usage: | Medical Apparatus, Machinery Equipment |
| Surface: | Polished, 400/600/800Grit |
| Heat Treatment: | Solutionheat-Treated |
| Company Info. |
| TORICH INTERNATIONAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
Standard | ASTM A269 Seamless and Welded Austenitic Stainless Steel Tubing |
Matrial | SUS304 |
Size | WT: 0.5mm-6.5mm OD: 15.88-203.2mm Length: as customers' requirement |
Technique | Cold Drawn Seamless or ERW Welded |
Surface Treament | Annealed, Brightly Annealed, Polish 400/600/800 grit |
Application | Construction Industry, Shipping Industry, Medical Apparatus,
Machinery Equipment and Water Series etc |
Manufacture | Pipes shall be made by the seamless or Welded process. At the manufacturer's option, tubing may be furnished either hot
finished or cold finished. |
Test | Tension Test, Flaring Test, Flange Test, Reverse Test, Hardness Test, Hydrostatic or Nondestructive Electric Test etc |
Chemical Requirements
Steel Grade | C | Si | Cr | Mn | Ni | P | S |
SUS304 | ≤0.08 | ≤1.00 | 18.00-20.00 | ≤2.00 | 8.00-11.00 | ≤0.045 | ≤0.030 |
Mechanical Properties
Tensile Strength (Mpa) | Yeild Strength (Mpa) | Enlongation (%) | Hardness |
520 | 205 | 40 | HB ≤187 HRB≤90 HV ≤200 |
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring
Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield
Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a
perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate
longitudinal and transversal defects.
PACKING:
Each tube in a plastic bag, then put tubes in a seaworthy woven bag
,each unit weight 400kg-500kg/bundle.
With strong wood structure box packing by containers loading and
shipping.
Or as customer's requirement.
20 ft container - GP: 5.8m (Length) * 2.13m (Width) * 2.18m
(Height) ------ Max Gross Weight: 25MT/container.
40 ft container - GP: 11.8m (Length) * 2.13m (Width) * 2.18m
(Height) ------ Max Gross Weight: 27MT/container.
40 ft container - HG: 11.8m (Length) * 2.13m (Width) * 2.72m
(Height) ------ Max Gross Weight: 27MT/container.
Port Shanghai
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and
solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is
30-60 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples of carbon seamless steel tube ? is it
free or extra ?
A: Yes, we could offer the sample for free charge but need pay the
cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30%
T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
|
