Disc Feeder Steel Plate Straightening Machine Metal Roll Punch Stamping Equipment

Disc Feeder, Metal Roll Stamping, Guangdong Punch Stamping Feeding Equipment

Although the name of the feeder of the disc feeder is actually a material rack, the name of the disc feeder is due to the fact that it uses a horizontal disc to horizontally place the coil, which can be quickly transported to the subsequent matching machine. material.

As the only horizontal material rack in the stamping industry, the disc feeder is the rack equipment developed by Ruihui Machinery for thin plate, narrow material and high speed stamping.

The utility model has the advantages of fast unwinding speed, no restriction on the inner diameter of the material, simple stacking, multi-roll stacking, simple operation, perfect speed synchronization by frequency conversion and speed regulation, and no scratching on the surface edge of the material.

1. The disc feeder has a fast unwinding speed and is suitable for use with any high-speed punching machine; the high-speed punching press has a fast stamping speed, which puts a rigid requirement on the running speed of the material rack and the leveling machine, and the feeding speed can reach 30m/min makes it suitable for any high-speed punch press production.

2. The disc feeder is not limited by the inner diameter of the coil. The coils can be stacked, and the feeding is simple and quick, and the refueling time is greatly saved.

Vertical material racks are all used in the tensioning and unloading method of the drum. Therefore, there is strict requirement on the inner diameter of the coil, and only one coil can be placed in one coil, and manual manual tensioning material is required. Rolls, loading is cumbersome, and it takes a long time to refuel a roll of material.

3. The disc feeder tracker can detect the unwinding speed in real time and automatically adjust the speed of the inverter to achieve the perfect match with the stamping production of the high-speed punch.

4, can be customized double-layer disc feeder, to meet the needs of customers double belt stamping production. The double-material belt stamping production line refers to the punching production of two strips in one time, and is the most advanced stamping production process.

It is also the inevitable trend of the industry, and the double-material belt stamping requires double-tape unwinding, leveling and feeding equipment. The double-layer disc feeder is the only one that can realize the double-tape simultaneous unwinding.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1^st,We have a high level of technical research and development team;

2^nd,We can provide the design and planning of the whole plant to realize the turnkey project;

3^rd, our philosophy: quality is the social responsibility;

4^th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;

5^th,We have a highly effective after-sales service team and get customer approval.
