Commercial 371 HP 8x4 Diesel Dump Truck , Sand Dump Truck Q235 Steel Body

Categories Heavy Duty Dump Truck
Brand Name: SINOTRUK HOWO
Model Number: ZZ3317N4667A
Certification: CCC/ISO9001/CE
Place of Origin: JINAN CITY OF CHINA
MOQ: 1 UNIT
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 5000 UNITS/Mouth
Delivery Time: 30-45 work days
Packaging Details: Package in Nude
Model: ZZ3317N4667A HOWO Dump Truck
Steering: ZF8118 Steering Gear Box
Cab: HW76 Low-floor Lengthen cab
Wheel base: 1800+4600+1350mm
Engine: WD615.47(Euro 2)
Clutch: SINOTRUK Φ430 diaphragm-spring clutch
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Commercial 371 HP 8x4 Diesel Dump Truck , Sand Dump Truck Q235 Steel Body

HOWO 371 HP 8x4 Dump Truck 12 wheels with German ZF8118 Steering Gear Box


SINOTRUK HOWO 8x4 Dump Truck Specifications

Body

Carriage Internal Dimensions(mm)8000x2300x1500
Cubage (m3)27.6
Steel thickness of Carriage(mm)Floor:8mm/Side:6mm
SteelQ235
Hydraulic Lift of CarriageFront Lift

Weight in kg

Kerb weight (Kg)10460
Gross vehicle weight (Kg)31000

Dimension(mm)



Dimensions(mm)

Length(mm)10315
Width(mm)2496
Height(mm)3125
Wheel base (mm)1800+4600+1350
Angle( ̊ )Approach14
Departure33

Performance

Maximum driving speed (km/h)82
Fuel consumption (1/100 km)46

Cab

ModelSINOTRUK HW76 Low-floor Lengthen cab
HW76 cab, (single sleeping, with air-condition), all-steel forward control,70̊ hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds,laminated windscreen with casted-in radio aerial,hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat,with heating and ventilating system,outer sun visor,adjustable roof flap,with stereo radio/cassette recorder,safety belts and adjustable steering wheel,air horn,with 4-point support fully floating suspension and shock absorbers.

Engine

ModelWD615.47(Euro 2)
Type6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
Horsepower371
Maximum output Kw/r/min274/2200
Maximum torque N.m/r/min1460/1300-1600
Bore x Stroke126x130mm
Valve2
Displacement9.726L
Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan
TransmissionSINOTRUK HW19710 transmission ,10 forward and 2 reverse

Clutch

SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

Steering

ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)

Front Axle

SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.
SuspensionFront overhang1500mm
Rear overhang1360mm

Rear Axles

SINOTRUK AC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.45;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading.

Brake System

Service brake:dual circuit compressed air brake

Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

Wheels & TyresRims10 hole-steel
Tyres12.00R20 radial tyre with 1 Spare tire.
Wheel tread2022/2022,2041/2041,1830/1830mm

Electrics

Operating voltage:24V,negative grounded

24V,7.5KW.Starter:24V,7.5 Kw

28V,1500W.Alternator:3-phase,28V,1500 W

2x12V,165Ah.Batteries:2x12 V,165 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light

Oil TankSquare type-300L Aluminum alloy fuel tank

Description:HOWO 8x4 Dump Truck is produced by SINOTRUK.And exported more than eighty countries and regions,for example Ethiopia,Kenya,South Africa,The Philippines,Saudi Arabia,Malaysia,Nigeria,Peru,Russia... It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials, which is the best choice for heavy construction vehicle customers.

Our advantages:

1. Warranty: one year or 10000 km

2. Production time: within 35 working days

3. After-sale service team:highly trained with overseas working experience

4. Support service:response quickly in 12 hours and provide professional technical

5. Shipping:professional transport team,safety and quickly
