metal geadhead 3V 6V 12V 24V micro gear reduction motors

Model: HT-SOG13

Product: Precise spur gear motor

Typical application :

1,Security and safe industry .

2,Robotics and automation

3,Electric valve

Gear Ratio Stage	2	3	4		5
Gear Ratio	10	35	115
	35	63	150
		86	360
Gearbox Length(L)	11

Drawing:

Reference data:

MODEL	VOLTAGE		NO LOAD		AT MAX EFFICIENCY
	OPERATION RANGE	NOMINAL	SPEED	CURRENT	SPEED	CURRENT	TORQUE
			r/min	A	r/min	A	kg.cm
HT-SOG13-121200	3.0-7.2	6.0	67	≤0.05	47	≤0.19	0.4
HT-SOG13-12342	3.0-7.2	6.0	27	≤0.05	19	≤0.19	1.2
HT-SOG13-12190	3.0-7.2	5.0	242	≤0.05	176	≤0.19	0.12
HT-SOG13-12139	3.0-7.2	5.0	134	≤0.05	98	≤0.19	0.23
HT-SOG13-12104	3.0-7.2	5.0	99	≤0.05	72	≤0.19	0.31
HT-SOG13-1280	3.0-7.2	5.0	74	≤0.05	52	≤0.19	0.4
HT-SOG13-1248	3.0-7.2	5.0	56	≤0.05	40	≤0.19	0.52
HT-SOG13-1233	3.0-7.2	5.0	23	≤0.05	16	≤0.19	1.20
HT-SOG13-05150	1.5-4.5	3	143	≤0.10	104	≤0.50	0.06
HT-SOG13-05100	1.5-4.5	3	79	≤0.10	57	≤0.50	0.12
HT-SOG13-0571	1.5-4.5	3	58	≤0.10	42	≤0.50	0.16
HT-SOG13-07250	1.5-4.5	3	33	≤0.10	24	≤0.50	0.27
HT-SOG13-0550	1.5-4.5	3	14	≤0.10	10	≤0.50	0.65

Pls note
The data sheet is only for your reference .
The speed is adjustable as per your request .
The gearbox can match other motor.
The shaft can be customized .

Company Information

Certificate:

Packaging & Shipping

metal geadhead 3V 6V 12V 24V micro gear reduction motors

SHENZHEN HOTEC CO.,LTD is ISO 9001 and ISO 14001 certificated manufacturer of DC motors and DC gear motors ,with both DC motor factory and gear motor facotry located in Shenzhen,China.

HOTEC MOTOR has been dedicated to offer reliable and cost-effective DC motor solution to customers‘ applications for more than 10 years . Nowadays ,we mainly focus on micro DC gear motors , including spur gear motor , planetary gear motor , and worm gear motors .

We pay full attention to each detail involved in customers‘ application, such as compact size , low noise , low current consumption , lifetime , low backlash etc .

Most importantly, we have engineers with more than 30 years‘ experience in this field , and professional R&D team , relying on this ,we have strong capacity , to design and produce custom gear motors to meet your demand !

Our history:

• 2004: DC motor factory was founded .
• 2006: Started sales to US Market .
• 2009: Started to apply automatic machines to replace workers.
• 2010: International sales Department was official founded .
• 2012: Another factory for gear motor was founded .
• 2013: Run two Brands and began promotion .
• 2014: The production capacity is 40K/day for DC motor , and 4k/day for gear motor .
• 2015: Widely apply automatic machines . The annual turnover reached up to 11 million USD . R&D expense cover 6% of the turnover .
