Round Stainless Steel Mini Air Cylinder CRDSW Type With Bore 32 - 63mm
Quick Detail:
* CRDSW type Round Stainless Steel Pneumatic Mini Cylinder
* With magnet,air buffer adjustable or rubber cushion for choice
* Stainless steel barrel,Aluminum tube can be optional
* Piston rod #45(ASTM-1045) steel chrome-plated
* Stainless steel piston rod is available
* With guide plate type available
* With self-lubricating bearing,lubrication free
* Bore size 32mm,40mm,50mm,63mm
* Cylinder kits and accessories available
Specifiction
| Bore (mm) | 32 | 40 | 50 | 63 |
| Motion Pattern | Double Acting or Single Acting | |||
| Working Medium | Air | |||
| Fixed Type | Normal Type/ LB Type/ FA Type/ SDB Type | |||
| Working Pressure Range | 1~9.0MPa | |||
| Ensured Pressure Resistance | 13.5MPa | |||
| Operating Temperature Range | 0~70℃ | |||
| Operating Speed Range | 50~800mm/s | |||
| Buffer Type | Gasket Buffer / Adjustable Buffer | |||
| Port Size | G1/8″ | G1/4" | G3/8″ | |
Stroke
| Bore(mm) | Stroke | Max.Stroke | Permissible Stroke |
| 32 | 1…500 | 500 | 800 |
| 40 | 1000 | ||
| 50 | 1200 | ||
| 60 | 1500 |





|
