RCM Certified 24W AUS Plug AC DC Adapter - 12V 2A / 24V 1000mA
Switching Power Supply
This 24W AC DC adapter is RCM certified and fitted with a standard
AUS plug, meeting strict Australian safety and performance
standards. It offers dual voltage outputs—12V 2A and 24V 1000mA
(1A)—to reliably power a wide range of devices, from consumer
electronics and small appliances to office gadgets and hobby
equipment.
The compact switching power supply design ensures stable,
consistent power delivery, while the AUS plug fits seamlessly into
Australian standard outlets. Ideal for home, office, or daily use,
it combines certified safety, multi-device compatibility, and
durable construction for all your AC/DC power needs.
1, Extreme small and space-saving, takes up one spot on power strip
2, AC input power suitable for the world
3, Meet DOE/CEC/ERP Level VI
4, Over voltage, over current, short circuit and over load
protection
5, Per pieces adapter is 100% full load -burn in test (4 hours)
6, All the products have passed the full load test process aging
7, Low interference & noise
8, Standard: EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347
9, Certification: UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA
| Datasheet |
| Input | 100 to 240V AC , 50 / 60Hz |
| Output power | 24W max |
| Output Range | 5 ~ 48V / 500mA ~ 3000mA |
| Protection | Over load protection |
| Over voltage protection |
| Short circuit protection |
| Safety Approvals | UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA |
| Standard | EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347 |
| Efficiency | Compliant with the lastest U.S energy regulation EISA
2007/DOE(Level VI), EU ErP and CoC version 5 |
| AC plug | EU / US / UK / AU and Others for your selection |
| Standard DC Connector | 5.5*2.5 / 5.5*2.1 /5.5*1.7 / 4.8*1.7 / 4.0*1.7 / 3.5*1.35 / 6.3*3.0
with pin inside |
| Operating Temperature Range | 0--40°C |
| Storage Temperature Range | -20 --- 85°C |
| High Humidity Operation | + 40 °C and 90 ~ 95% Humidity |
| Net weight | About 120g per unit |
| MTBF | 50,000 hours |
| Application | Consumer electronic devices · Telecommunication devices · Office
facilities · Industrial equipments |
| Packing | PE bag + Carton or White Box + Carton or As your Request |
