DIN 1.4462 Duplex Stainless Steel Plates , stainless steel metal sheet Grade 2205 EN10204-3.1

Categories	Stainless Steel Plates
Brand Name:	Baosteel/Tisco
Model Number:	201 202 304 304L 309S 310S 321 316L 317L 347 329.etc
Certification:	ISO/BV/SGS
Place of Origin:	Jiangsu/China
MOQ:	1 ton
Price:	USD1000-5000 per ton
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	300tons per month
Delivery Time:	within 10days after received the payment
Packaging Details:	Standard seaworthy packaging / as per buyer’s request
Thickness:	0.3-3.0mm
Standard:	ASTM, AISI, DIN, EN, GB, JIS
Length:	Customer's Request
Width:	500-2000mm
Technique:	Cold Rolled Hot Rolled
Material::	2205 / UNS S32205

Contact Now

Add to Cart

Company Info.

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

DIN 1.4462 Duplex Stainless Steel Plates , stainless steel metal sheet Grade 2205 EN10204-3.1

DIN 1.4462 Duplex Stainless Steel Plates Grade 2205 EN10204-3.1

Duplex Stainless Steel Plate
Grade 2205 2507 S32304 S32550.S32101 S31260.etc
Standard: ASTM JIS GB EN DIN
Thickness: 0.4 - 60.0mm
Width: 1000mm 1219mm 1500mm 2000mm or as required
Brand: TISCO JISCO BAOSTEEL NIPPON

Specifications

Commodity	Duplex stainless steel plate UNS S32205
Width	1000MM 1219mm 1500mm, 1800mm, 2000mm
Thickness	0.6 – 60.0mm
Surface	NO.1 2B
Main Grade	201 202
	304 304L 309S 310S 321 316L 317L 347 329.etc
	409L 410 420 430 436L 439 441 444
	duplex stainless steel
	Nickel Alloy products
Standards	ASTM A240 / JIS G4303 / GB3280-84/EN10088-1/DIN
Certifications	ISO 9001-2008
Standard Size	1500 * 6000mm / 1800 * 6000mm
Brand	TISCO BAOSTEEL / JISCO / LISCO / POSCO / OUTOKUMPU/NIPPON/CHENGDE
Loading Port	Shanghai Port,China
Paymentterms	L/C or T/T
Delivery time	5 – 12 days according the quantity.

Duplex 2205 stainless steel (both ferritic and austenitic) is used extensively in applications that require good corrosion resistance and strength. The S31803 grade stainless steel has undergone a number of modifications resulting in UNS S32205, and was endorsed in the year 1996. This grade offers higher resistance to corrosion.
At temperatures above 300°C, the brittle micro-constituents of this grade undergo precipitation, and at temperatures below -50°C the micro-constituents undergo ductile-to-brittle transition; hence this grade of stainless steel is not suitable for use at these temperatures.

Composition

Table 1 provides the compositional ranges for grade 2205 duplex stainless steel.
Table 1 - Composition ranges for 2205 grade stainless steels

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
2205 (S31803)	Min Max	- 0.030	- 2.00	- 1.00	- 0.030	- 0.020	21.0 23.0	2.5 3.5	4.5 6.5	0.08 0.20
2205 (S32205)	Min Max	- 0.030	- 2.00	- 1.00	- 0.030	- 0.020	22.0 23.0	3.0 3.5	4.5 6.5	0.14 0.20

Grade specification comparisons for 2205 grade stainless steels

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
Grade	UNS No	BS	En	No	Name	Swedish SS	Japanese JIS
2205	S31803 / S32205	318S13	-	1.4462	X2CrNiMoN22-5-3	2377	SUS 329J3L

Applications

Some of the typical applications of duplex steel grade 2205 are listed below:

Oil and gas exploration
Processing equipment
Transport, storage and chemical processing
High chloride and marine environments
Paper machines, liquor tanks, pulp and paper digesters

Chemical Composition of our duplex stainless steel

Designation			Chemical composition % by mass max unless stated
UNS No	SAE No	AISI No / Common Name	C	Si	Mn	P	S	Cr	Mo	Ni	Others
S31100	-	XM-26	0.06	1.00	1.00	0.045	0.030	25.0/27.0	-	6.0/7.0	Ti 0.25
S31200	-	44LN	0.030	1.00	2.00	0.045	0.030	24.0/26.0	1.20/2.00	5.5/6.5	N 0.14/0.20
S31260	-	DP3	0.03	0.75	1.00	0.030	0.030	24.0/26.0	2.5/3.5	5.5/7.5	N 0.10./0.30; Cu 0.20/0.80; W 0.10/0.50
S31500	-	3RE60	0.03	1.4/2.0	1.2/2.0	0.03	0.03	18.0/19.0	2.5/3.0	4.25/5.25	N 0.05/0.10
S31803	-	2205	0.030	1.00	2.00	0.030	0.020	21.0/23.0	2.5/3.5	4.5/6.5	N 0.08/0.20
S32001	-	Nitronic 19D	0.030	1.00	4.0/6.0	0.040	0.030	19.5/21.5	0.60	1.00/3.00	N 0.05/0.17; Cu 1.00
S32003	-	AL 2003	0.030	1.00	2.00	0.030	0.020	19.5/22.5	1.50/2.00	3.0/4.0	N 0.14/0.20
S32101	-	LDX 2101	0.040	1.00	4.0/6.0	0.040	0.030	21.0/22.0	0.10/0.80	1.35/1.70	N 0.20/0.25; Cu 0.10/0.80
S32202		DX 2202	0.030	1.00	2.00	0.040	0.010	21.5/24.0	0.45	1.00/2.80	N 0.18.0.26
S32205	-	2205 UR45N	0.030	1.00	2.00	0.030	0.020	22.0/23.0	3.0/3.5	4.5/6.5	N 0.14/0.20
S32304	-	2304	0.030	1.00	2.50	0.040	0.030	21.5/24.5	0.05/0.60	3.0/5.5	N 0.05/0.20; Cu 0.05/0.60
S32404	-	Uranus 50	0.04	1.0	2.0	0.030	0.010	20.5/22.5	2.0/3.0	5.5/8.5	N 0.20; Cu 1.0/2.0
S32520	-	Uranus 52N+	0.030	0.80	1.50	0.035	0.020	24.0/26.0	3.0/4.0	5.5/8.0	N 0.20/0.35; Cu 0.50/2.00
S32550	-	Ferralium 255	0.04	1.00	1.50	0.040	0.030	24.0/27.0	2.9/3.9	4.5/6.5	N 0.10/0.25; Cu 1.50/2.50
S32750	-	2507	0.030	0.80	1.20	0.035	0.020	24.0/26.0	3.0/5.0	6.0/8.0	N 0.24/0.32; Cu 0.50
S32760	-	Zeron 100	0.030	1.00	1.00	0.030	0.010	24.0/26.0	3.0/4.0	6.0/8.0	N 0.20/0.30; Cu 0.5/1.00; W 0.50/1.00
S32900	-	329 44L 453S	0.08	0.75	1.00	0.040	0.030	23.0/28.0	1.00/2.00	2.0/5.00	-
S32906	-	-	0.030	0.50	0.80/1.50	0.030	0.030	28.0/30.0	1.50/2.60	5.8/7.5	N 0.30/0.40; Cu 0.80
S32950	-	7Mo Plus	0.030	0.60	2.00	0.035	0.010	26.0/29.0	1.00/2.50	3.5/5.2	N 0.15/0.35
S39226	-	-	0.030	0.75	1.00	0.030	0.030	24.0/26.0	2.50/3.50	5.50/7.50	N 0.10/0.30; Cu 0.20/0.80; W 0.10/0.50
S39274	-	DP3W	0.030	0.80	1.0	0.030	0.020	24.0/26.0	2.50/3.50	6.0/8.0	N0.24/0.32; Cu 0.20/0.80; W 1.50/2.50
S39277	-	AF918	0.025	0.80	0.80	0.025	0.002	24.0/26.0	3.0/4.0	6.5/8.0	N 0.23/0.33; Cu 1.2/2.0; W 0.80/1.20
S82011		AL 2102	0.030	1.00	2.0/3.0	0.040	0.020	20.5/23.5	0.10/1.00	1.0/2.0	N 0.15/0.27
S82441		LDX 2404	0.030	0.7	2.5/4.0	0.035	0.005	23.0/25.0	1.00/2.00	3.0/4.5	N 0.20/0.30 Cu 0.10/0.80

DIN 1.4462 Duplex Stainless Steel Plates Grade 2205 EN10204-3.1
