| Brand Name: | WISCO |
| Model Number: | AH36 |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 1 ton |
| Price: | 680 USD/Ton |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 tons per month |
| Delivery Time: | 7 days |
| Packaging Details: | Export Packing |
| Standard: | AISI, ASTM, BS, DIN, GB, JIS |
| Type: | Steel Plate |
| Application: | Ship Plate |
| Special Use: | High-strength Steel Plate |
| Technique: | Hot Rolled |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
Astm A131 Grade A Ship Steel Plate , AH36 Shipbuilding Steel Plate 6.0*2000*6000mm
ASTM A131 AH36 steel plate, AH36 steel is a kind of steel for shipbuilding and platform. Shipbuilding steel plate AH36 is the high tensile strength steel.
ABS steels come 4 grades in ordinary-strength steel for shipbuilding and grade A is the lowest one of them. The ABS A grade steel plates have yield strength of 34,100 psi (235 MPa), and ultimate tensile strength of 58,000 - 75,500 psi (400-520 MPa). All the ABS/A shipbuilding Steel offered by Baoxin Steel Group can be certificated by American Bureau of Shipping(ABS).
1.Thickness:6~100mm
2.Width:1000~4800mm
3.Length:1000~18000mm
Grade | C max | Si max | Mn | P max | S max | Als min | Ti max | Cu max | Cr max | Ni max | Mo max | Nb | V |
| AH36 | 0.18 | 0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 | 0.02-0.05 | 0.05-0.10 |
Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.38% (thickness ≤ 50mm),≤0.40%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
| Grade | Rm (MPa) | Re(MPa) min | A% min | Akv/J min | ||||||
| AH36 | 490-630 | 355 | 21 | E.T °C | Thickness (mm) | |||||
| 0 | ≤ 50 | >50-70 | >70-100 | |||||||
| L | C | L | C | L | C | |||||
| 34 | 24 | 41 | 27 | 50 | 34 | |||||
Note: In the list , Rm: .tensile strength,Re: Yield strength,A%: elongation, E.T: experimental temperature,L: lengthways, C: crosswise.
|
