P10 Outdoor LED Video Wall 320x160mm Full Color Advertising Screen

Categories Advertising LED Screens
Brand Name: SCXK
Model Number: P10
Certification: CE/ROHS/FCC/ISO/UL
Place of Origin: ShenZhen in China
MOQ: 5sqm
Price: negotiation
Payment Terms: Western Union,MoneyGram,D/P,T/T,L/C
Supply Ability: 5000sqm per month
Delivery Time: 7-10 working days after receive your payment
Packaging Details: flight case, wooden case, carton, it is up to you.
Pixels: 10mm
Tube Chip Color: Full color
Cabinet material: Iron or Aluminum For Options
pixel configuration: 1R1G1B
warranty: 3 years
Pixel density: 10000dots/sqm
Module Size: 320*160mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

P10 Outdoor LED Video Wall 320x160mm Full Color Advertising Screen

Outdoor P10 Full Color 320*160mm High Brightness LED Video Wall Commercial Advertising Billboards


Advantages of Led display

(1) High brightness DIP LED is used for outdoor led display, keeps the display content visible even if facing the strong sunshine directly.

(2) With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.

(3) Weatherproof design, completely outdoor use.

(4) Easy for assembling and connection with the connector added.

(5) High color uniformity and clear image can bring you a vivid audio visual effect.

(6) Both front and rear access are available.

(7) The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.

(8) Use the same level of red, green and blue led chips, which makes the image display of whole led display more excellent and uniform.

(9) The maintenance of pixel and single led has been realized.

(10) Good quality raw material, accurate technique and careful inspection insures the high quality of led display


Cabinet: Die casting aluminum and waterproof iron cabinet are available

1.Classical design and natural technic,reliable quality and great performance.
2.Seamless connecting tech.,screen flatness error <0.1mm.
3.Patented mask,eliminating the dark spots,improving consistency and viewing angle.
4.High contrast,ideal gray scale,presenting the most real pictures.
5.Supporting brightness and color correcting of the whole screen.
6.Ideal load of power and parameter setting,make screen under the best working condition,moreover,furthest slow down brightness and color reduction.


Product specification

outdoor SMD P10
Lamp size3535
Resolution/mm10
Pixel configurationRGB 3 in 1
Pixel density/pixels/m²10000/m²
Module resolution32x16
Module size/mm320x160
View distance≥10m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>5000cd/㎡
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle120(degrees)
Signal Process bit10 or 14 bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
Driving modeConstant driving current
Scanning mode1/4
Frame rate60Hz
Refresh frequency>1200Hz
Control modeComputer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>7000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
Installation Process
Applications
Certifications
Our former product like transparent soft LED display have CE, FCC and Rhos certificate, our new foldable flexible LED module display will have EC certificate soon, don't worry about the certificate, our product is complied of every international standard, so it is not hard to pass the CE criteria and we will get CE certificate soon

Packaging

Quality

100% brand new.


Payment

Bank transfer or Western Union, L/C, and etc.


Packing and delivery

Within 30 working days after confirming payment.

Packed in anti-static bags,bubble bags,foam box and carton to ensure safety in transportation, or customized single box.


Shipping

by airway, Freight, or depends on your requirement, the packing photos and the tracking number will be updated after delivery.


After-sale service

Please feel free to contact us for any problem any time, we will help you solve.
