Vertical Parking System Car Mini Lift Residential Pit Garage Parking Car Lift

Vertical parking system car mini lift residential pit garage parking car lift​ with CE

Product Description

Model	SJG3-5
Loading capacity	3000kg
Lift height	5000mm
Lift platform size	5200mm*2600mm
Material	High Strength Manganese Steel
Note	The car scissor lift can be customized as your request.

Configuration:

1. Platform Material: rectangular tube +checkered steel plate

2. Scissor material: high strength Manganese Steel

3. Hydraulic system: 380V/5.5Kw

4. Piston Rod: hard chromium plating surface

5. Controller: 1 control box below, 1 control panel above platform

Testing

All the hydraulic car lift for home garage are passed 1.2 times loading test before leaving factory.

​

​

Other Feature

1) The safe handrail to guarantee safety of the cars above the platform.

2) The limit switch system helps hydraulic car lift for home garage to stop at accurate position.

3) Electricity leakage protection device is equipped on, all electric components are CE certified.

4) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.

5) High Precision Hydraulic Cylinder: (high-pressure oil pump,Hydraulic oil: summer 46#, winter 32#).

Control System

Packing & Delivery

Iron case or plywood case package or your request.

Installation Site
