| Categories | Corrugated Roofing Sheets |
|---|---|
| Brand Name: | Minto |
| Model Number: | Minto RF-02 |
| Certification: | SGS |
| Place of Origin: | China |
| MOQ: | Negotiation |
| Price: | Negotiation |
| Payment Terms: | LC TT AS Discussed |
| Supply Ability: | 10000MT/Month |
| Delivery Time: | Within 20-30days after getting the deposit or L/C |
| Packaging Details: | Seaworthy packing |
| Name: | Corrugated Aluminum Roofing/Wave Tile Gi Steel |
| Paint Thickness: | Top side:6+11 micron Back side:5-7 micron or based on customer's requirement |
| Base Plate: | GI/GL/PPGI/PPGL |
| Product Feature: | Water resistance,light weight,easy installation,high tensile |
| Usage: | Home Roofing Interior Wall |
Galvanised Aluminium Corrugated Roofing Sheets For Home Interior Wall
Galvanized Corrugated Roofing Sheet
1. Describtion
Thickness: . 0.2-0.8mm
Width: 665-1050mm
Packing: Waterproof packing
Commodity Galvanized corrugated sheet
Width 665-1050mm
Wall thickness 0.2-0.8mm
Length any length
Standard SGCC
2. Common Forms
Common Size as followings:
762mm to 665mm(after corrugated) and 9 waves
914mm to 750mm (after corrugated) and 12 waves
1000mm to 890mm or 900mm(after corrugated) and 12 or 14 waves
We can produce according to the client's requirement
3.Feature of galvanized color coated corrugated roofing sheets as
followed roofing sheet
1) Outlook Beautiful and novel, rich colors, flexible combination,
can be used in different building to express special original
architectural styles in life
2) Surface have been treated as galvanized and color coated.so it
can anti-rain,anti-fire,anti-quake,So it has a long term life as
20-30 year and color just not fade.
3) Light weight: easy to transport the material,short the time to
finish the building,reduce worker's hard work,save much time and
energy for human beings
4) Smooth surface treatment,the dust will be easy taken off by the
rain
5) Environmental material,can be used many times,will do no hard to
the our environment.
(6) 1000 width,and 880 effective width or as your requirement,for
easy set up .
(7) Prime anti-fire application,which is confirmed by GB50222-95 as
difficult to fire as B
(8) Impact resistance, strength is 250-300 times of common
glass,2-20times of tempered glass,
(9) Energy saving: keep summer cool,winter warm.Heat insulation
effect is higher 7%-25% than that of the common glass,then heat
loss is greatly reduced.
(10) insulation resistance: corrugated sheet with obvious effect of
noisy.
(11) Light in weight,and have very good beatification vision
effect.
| Base metal | Cold rolled steel coil,full hard cold rolled steel coil |
| Material | SGCC,SGCH, Full hard |
| Grade: | Commercia.Quality(CGCC,DX51D,DC01,SPCC), Structure.quality(S280GD,S320GD,S350GD). Deep.drawing.quality(DX52D,DX53D,DX54D,DX56D) |
| Standard | ASTM A653 CS/B,JIS G3302,DIN EN 10142,EN10327 |
| Applications | Advertising,building trade,home electrical, Electrical industry,decoration,office furniture |
| Thickness | 0.14mm-1.0mm |
| Tolerance | +/-0.03mm |
| Zinc layer | A40,A60,G60,G90,G115,G140,G165. Z12,Z18,Z22,Z25,Z27,Z35. Z60,Z80,Z100,Z120,Z150,Z180,Z220,Z275,Z350 |
| Width | 600mm,750mm,762mm,914mm,1000mm,1219mm,1200mm,1250mm,1500mm |
| Length | 1.5m,2.0m,2.438m,2.44m,2.5m,3m.,3.5m,4m,4.5m,5m |
| Surface treatment | Chromated,oiled/unoiled,skinpassed,Chromated+oiled |
| Surface state | Regular spangle,mini spangle,zero spangle, skinpassed |
| Coil weight | 4-8tons |
| ID | 508mm or 610mm |
| Packing | Export standard seaworthy packing. Waterproof paper+steel sheet+bundle with steel strips(3-4pcs) |
| Delivery | Based on the quantity. |
| Shipment | Bulk vessel or container (FCL/LCL) |
| Payment | T/T or LC at sight |
| Loading port | Main port of China,Shang hai,Qingdao,Dalian,Tianjin etc. |
| Yield strength | 285Mpa-305Mpa |
| Tensile strength | 340Mpa-370Mpa |



|
