| Categories | Expanded Metal Mesh Machine |
|---|---|
| Brand Name: | DIAOZHUO |
| Model Number: | DZ005 DZ009 DZ011 DZ021 |
| Certification: | CE ISO9001 |
| Place of Origin: | HEBEI, CHINA |
| MOQ: | 1set |
| Payment Terms: | T/T, D/P, L/C |
| Supply Ability: | 30 sets per month |
| Delivery Time: | 20-30 days |
| Packaging Details: | unde |
| Price: | variable |
| material: | printed |
| punching: | PLC control |
| colour: | as required |
| type: | BTO-10 BTO-22 CBT-6 |
Single tape razor barbed wire punching machine fully automatic
razor wire machine
Razor wire machine with one strip is light-style,easy to operate,convinent to maintain,competitive price. The machine is made of two parts.one is the main machine ,which produce the blade ,and the other is the coiling machine which coil the wire.
Razor barbed wire machine,is specially used to manufacture razor barbed wires.It mainly consists of punching razor strip machine,coiling wire machine and mould.The punching razor strip machine is used as punching the outside razor strip of razor wire .The coiling wire machine is used as coiling the wire into the razor strip to form the finished razor wire.The mould decide the razor length ,width the space.
Punching machine
| punching Plate thickness | 0.3-0.6mm |
| punching Plate width | 99-145mm |
| punching Production speed | 60-75times/min |
| Motor power | 2.2KW |
| Rated voltage | 380V 50HZ |
| Weight | 1.9T |
| Overall dimension | 1325*990*2140mm |
Coiling machine
| Voltage | 380V, 50Hz,or client’s required voltage |
| Power | 1.5kw |
| Producing speed | 80Kg/h |
| Wire diameter | 2.5mm |
| Weight | 300Kg |
| Dimension | 1100mm×750mm×1200mm |
Mould type
| Mould type | Barb Length | Barb width | Barb spacing |
| R1 | 12±1mm | 13±1mm | 26±1mm |
| R2 | 12±1mm | 15±1mm | 26±1mm |
| R3 | 18±1mm | 15±1mm | 33±1mm |
| R4 | 22±1mm | 15±1mm | 34±1mm |
| R5 | 28±1mm | 15±1mm | 34±1mm |
| R6 | 30±1mm | 18±1mm | 34±1mm |
| R7 | 60±1mm | 32±1mm | 96±1mm |
| R8 | 65±1mm | 21±1mm | 100±1mm |

|   |
