| Categories | Single Acting Hydraulic Cylinder |
|---|---|
| Brand Name: | Dallast |
| Model Number: | 3/4/5/6 Stage |
| Certification: | GS CE ISO9001 |
| Place of Origin: | Shandong China |
| MOQ: | 1 piece |
| Price: | negotation |
| Payment Terms: | T/T, Western Union, D/A, D/P, L/C |
| Supply Ability: | 50000 Pieces/Per year |
| Delivery Time: | 15-25 days |
| Packaging Details: | Carton or According to Customer's Require |
| Capacity: | OEM ODM Sample |
| Service: | After-sale Service |
| Type: | Hydraulic single acting |
| Installation: | Front End Loader |
| Color: | Optional |
Press Dump Truck Single Acting Hydraulic Cylinder 3 Stage Piston Rod
Product Advantage
TG is a single-acting hydraulic cylinder multi-section telescopic lifting cylinder sleeve. It has small size, stroke length and other characteristics and mainly used for hydraulic systems of engineering and Dump truck.
| Color | more color |
| Product material | high manganese steel |
| Working pressure | 5-36MPa |
| Min order | 1 piece |
| Supply ability | according to customers/ request produce |
| Delivery time | within 10-15 days after contract establish |
| Warranty time | 6 month |
| Main markets | south Asia/ Mid East/ Africa/ Southeast Asia/ North America/ South America |
| Materials of Hydraulic cylinder tube | 45# steel,27SiMn |
| Technical Treatment of Piston Rod | Quenched and tempered. chromed |
What is the information we require for customer before we make the quotation?
| MODEL NO. | Largest Stage Diameter | Stroke | The largest sleeve OD | Mounting distance |
| (mm) | (mm) | (mm) | (mm) | |
| FC-3-110-3205 | 110 | 3205 | 168 | 343 |
| FC-3-110-3460 | 110 | 3460 | 168 | 343 |
| FC-3-129-2980 | 129 | 2980 | 218 | 343 |
| FC-3-129-3205 | 129 | 3205 | 218 | 343 |
| FC-3-129-3460 | 129 | 3460 | 218 | 343 |
| FC-3-129-3880 | 129 | 3880 | 218 | 343 |
| FC-3-129-4270 | 129 | 4270 | 218 | 343 |
| MODEL NO. | First Stage Diameter | Stroke | Largest Sleeve OD | Mounting distance |
| (mm) | (mm) | (mm) | (mm) | |
| FC-3-107-2855 | 107 | 2855 | 152 | 311 |
| FC-3-107-3115 | 107 | 3115 | 152 | 311 |
| FC-3-107-3265 | 107 | 3265 | 152 | 311 |
| FC-3-107-3415 | 107 | 3415 | 152 | 311 |
| FC-3-107-3715 | 107 | 3715 | 152 | 311 |
| FC-3-126-3230 | 126 | 3230 | 219 | 343 |
| FC-3-126-3680 | 126 | 3680 | 219 | 343 |
| FC-3-126-3830 | 126 | 3830 | 219 | 343 |
| FC-3-126-4400 | 126 | 4400 | 219 | 343 |
Features:
1. Multistage telescopic long stroke hydraulic cylinder applies to long stroke lifting operation.
2. Surface corrosion treatment, bright color, not east to rust.
3. High strength alloy steel with high grade heat treatment, produced by imported CNC lathe, drilling machine and grinding machine.
4. Import seeling parts, not easy to wear after continuous working.
5. Dust ring reduces contamination, extending cylinder life.
6. Single acting, load return.
7. R2 3/8 coupler and dust cap included on all models.
8. Flat saddle is standard, and tilting saddle is available.
|
