| Categories | Auto Exhaust Flexible Pipe |
|---|---|
| Brand Name: | Connect |
| Model Number: | 201 202 |
| Certification: | ISO/TS16949 |
| Place of Origin: | Zhejiang,China |
| MOQ: | negotiation |
| Price: | negotiation |
| Payment Terms: | L/C T/T |
| Supply Ability: | 100 thousand pcs/m |
| Delivery Time: | within 30dd |
| Packaging Details: | Plastic bag + carton box+pallet |
| Description: | Auto exhaust flexible pipe without inner liner |
| Main Material: | 201 202 |
| ID: | 38mm~76mm |
| Overall length: | 51mm~356mm |
| Shipping terms: | FOB CFR CIF |
| Package: | plastic bag plus carton box |
| Brand: | Connect |
| Payment terms: | T/T L/C |
| Auxialiary materials: | Stainless steel or Aluminum |
201 202 exhaust flexible pipe without inner liner for auto exhaust systems
MATERIALS
| Bellows/Outer braid | Stainless steel 201 202 |
| Other materials available for bellows | 304 309S 321 |
| Caps | Aluminum Steel or stainless steel |
SUPPLY RANGE
Inner Diameter: 38mm~76mm(1.5"-3")
Overall length(Nipple length excluded):51mm~356mm(2"-14")
SIZE AVAILABLE
| Inner Diameter(ID) | Length(L) | Inner Diameter(ID) | Length(L) | ||||
| Inch | mm | Inch | mm | Inch | mm | Inch | mm |
| 1-3/4" | 45 | 4" | 102 | 2-1/4" | 57.2 | 4" | 102 |
| 6" | 152 | 6" | 152 | ||||
| 7" | 178 | 8" | 203 | ||||
| 8" | 203 | 9" | 230 | ||||
| 9" | 230 | 10" | 254 | ||||
| 10" | 254 | 11" | 280 | ||||
| 11" | 280 | 12" | 305 | ||||
| 12" | 305 | - | - | ||||
| 2" | 50.8 | 4" | 102 | 2-1/2" | 63.5 | 4" | 102 |
| 6" | 152 | 6" | 152 | ||||
| 8" | 203 | 8" | 203 | ||||
| 9" | 230 | 9" | 230 | ||||
| 10" | 254 | 10" | 254 | ||||
| 11" | 280 | 11" | 280 | ||||
| 12" | 305 | 12" | 305 | ||||
| 3" | 76.2 | 4" | 102 | ||||
| 6" | 152 | ||||||
| 8" | 203 | ||||||
| 10" | 254 | ||||||
| 12" | 305 | ||||||
Note: for other's not routine ID, such as 32 38 40 46 48 52mm, the length could be customized upon request
PROFILE

A CORNER OF PACKAGE

APPLICATION:
Such kind of exhaust flexible pipe is widely used in some Korea brand cars



|
