| Categories | Split Solar Water Heater |
|---|---|
| Brand Name: | PASSION/OEM |
| Model Number: | 300L/1000L |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000units/month |
| Delivery Time: | 10 working days |
| Packaging Details: | CARTONS/PLYWOOD CASE/PALLET |
| Capacity: | 2000L/1500L |
| Structure: | Split System |
| Flat Plate: | Black Chrome |
| Principle: | Pressurized |
| Collector: | Flat Plate |
| Inner Tank: | Stainless Steel 304/316 |
| Bracket: | Stainless Steel 201 0/20/30/45 degrees |
| Material: | Copper Aluminum |
| Company Info. |
| JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
300L Flat Collector 1000L Stainless Steel Heat Pipe Split Solar Water Heater 2 Coils
Advantage:
1. Highly efficient absorber of high performance with daily average
efficiency over 76%;
2. Blue film absorber with automatic production line,can supply you
stable high quality products;
3. Withstand pressure of 6 Bar, can be connected directly with city
water or your big water tank;
4. Simple structure, easy to assembly and install in short time, no
breakage;
5. Best insulation with polyurethane foam;
6. Can be used all year round in the cold climate;
7. Can be used together with auxiliary electric boost;
8. Long service life, can be used over 15 years;
Flat Plate Solar Water Heater Features:
1.Using patent advanced coating technology with high efficiency performance.
2. High strength aluminum-alloy structure with surface varnish baking
3. High visual shape ,easy installation ,maintenance free
4. Pressurized designing, operate with pressure up to 1 Mpa
5. Can be combined with existing energy source
Heat Pipe Split Solar Water Heater with Double Coils
| Model | PTS-H2-15 | PTS-H2-20 | PTS-H2-25 | PTS-H2-30 | PTS-H2-40 | PTS-H2-50 | PTS-H2-100 | |
| Heat Pipe Solar Collector | Tubes (PCS) | 15 | 20 | 25 | 30 | 40 | 50 | 100 |
| Three Target Vacuum Tube | Diameter/Length: φ58mm/1800mm; High boron and silicon content 3.3; Structure:Gradual change SS-AL-Nx/Cu selective absorption coating; Vacuum Degree:P<=5*10-3; | |||||||
| Heat Pipe | Condesor: φ14*70mm; Thickness: 0.5mm ; Material: red copper TU1+water; Transfer Power:>=150W; Working Pressure:4Mpa; Welding Pressure:4Mpa; | |||||||
| Outer Shell/Bracket - Alluminum Alloy | Insulation Layer - Rock wool | Dustproof Rubber - EPDM | Dsily Heat Gain - 8.5MJ/m² | |||||
| Inlet/outlet - 22mm/3/4" | Tailstock - ABS | Temperature - 250 °С | Work Pressure - 0.6MPa | |||||
| Contour Area | 2.32m² | 3.10m² | 3.78m² | 4.52m² | 6.20m² | 7.56m² | 15.12m² | |
| Aperture Area | 1.43m² | 1.89m² | 2.36m² | 2.83m² | 3.8m² | 4.72m² | 9.44m² | |
| Absorption Area | 1.22m² | 1.62m² | 2.04m² | 2.43m² | 3.24m² | 4.06m² | 8.16m² | |
| Quantity (PCS) | 15tubes*1 | 20tubes*1 | 25tubes*1 | 30tubes*1 | 20tubes*2 | 25tubes*2 | 25tubes*4 | |
| Water Tank | Capacity | 150L | 200L | 250L | 300L | 400L | 500L | 1000L |
| Top Copper Coil (mm*M) | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*20 | Φ19*30 | |
| Bottom Copper Coil (mm*M) | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*25 | Φ16*30 | Φ19*40 | |
| Polyurethane Foaming (mm) | 55 | 50 | 50 | 50 | 60 | 60 | 100 | |
| Outer Tank | Color Steel Plate/ Enamal White | |||||||
| Φ470/0.5 | Φ550/0.5 | Φ580/0.5 | Φ580/0.5 | Φ700/0.5 | Φ700/0.5 | Φ1000/0.5 | ||
| Inner Tank | SUS 304 2B , Working pressure-6 bar, Test pressure-12 bar | |||||||
| Φ360/1.2 | Φ450/1.5 | Φ480/1.5 | Φ480/1.5 | Φ580*2.0 | Φ580*2.0 | Φ800/2.5 | ||
| Electrical Heater | 1500W | 1500W | 2000W | 2000W | 2000W | 2000W | 4000W | |
| Working Station | SR961S (Including controler & WILO PUMP) | |||||||
| Expansion Tank | 8L | 8L | 8L | 8L | 12L | 12L | 24L | |
Flat Panel Split Solar Water Heater with Double Coils PTS-F2
| Model | PTS-F2-15 | PTS-F2-20 | PTS-F2-25 | PTS-F2-30 | PTS-F2-40 | PTS-F2-50 | PTS-F2-100 | |
| Flat Panel Solar Collector | Core material | Copper | ||||||
| Coating | Copper aluminum cover coating of Blue Titanium Absorption rate: α=0.95 Reflection rate ε=0.04. | |||||||
| Base plate | Marine-grade H3004 Aluminum, toughnessH32 Thickness 0.7mm | |||||||
| Glass of panel | Special glass for panel With ANS1297-1-1975, BS6206A and JIS R3206 standards; toughness with AS2208-1978 and federal standards of United States. | |||||||
| Panel Insulation | Bottom with fiberglass insulation ,Thickness 60mm,Density 20kg/m³; Side-thickness insulation:13mm; Density 23kg/m³; Thermal properties: R1.0 Thermal conductivity : 0.059W/m． | |||||||
| Quantity (PCS) | 1 | 1 | 2 | 2 | 3 | 3 | 6 | |
| Water Tank | Capacity | 150L | 200L | 250L | 300L | 400L | 500L | 1000L |
| Top Copper Coil (mm*M) | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*20 | Φ19*30 | |
| Bottom Copper Coil (mm*M) | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*15 | Φ16*25 | Φ16*30 | Φ19*40 | |
| Polyurethane Foaming (mm) | 55 | 50 | 50 | 50 | 60 | 60 | 100 | |
| Outer Tank | Color Steel Plate/ Enamal White | |||||||
| Φ470/0.5 | Φ550/0.5 | Φ580/0.5 | Φ580/0.5 | Φ700/0.5 | Φ700/0.5 | Φ1000/0.5 | ||
| Inner Tank | SUS 304 2B , Working pressure-6 bar, Test pressure-12 bar | |||||||
| Φ360/1.2 | Φ450/1.5 | Φ480/1.5 | Φ480/1.5 | Φ580*2.0 | Φ580*2.0 | Φ800/2.5 | ||
| Electrical Heater | 1500W | 1500W | 2000W | 2000W | 2000W | 2000W | 4000W | |
| Working Station | SR961S (Including controler & WILO PUMP) | |||||||
| Expansion Tank | 8L | 8L | 8L | 8L | 12L | 12L | 24L | |
Flat Plate Solar Collector Technical Data :
Model | PT-F-AO | PT-F-BC | PT-F-BT | |||
Data | ||||||
Dimension LxWxH (mm) | 2000*1000*80 / 2000*1250*80 / 2000*1500*80 | |||||
Gross Area (m2 ) | 2.00 | |||||
Absorber Area (m2 ) | 1.9 | |||||
Number of covers | 1 | |||||
Cover Material | Low iron tempered textured glass | |||||
Cover Thickness(mm) | 3.2 | |||||
Cover Transmission | >91.7% | |||||
Weight (KGS) | 29 | |||||
Absorber | ||||||
Absorber material | Aluminium Plate | |||||
Absorber coating | Anode Oxidation | Black Chrome | Blue Titanium | |||
Welding | Laser welding/Ultrasonic welding | |||||
Construction Type | Grid type | Grid type | Grid type | |||
Header Material | Copper TP2 | Copper TP2 | Copper TP2 | |||
Header pipe | Red copper/ Φ22*0.6*2 PCS | |||||
Riser Material | Copper TP2/CA1220 | |||||
Riser pipe | Red copper/ Φ8*0.5*7 PCS/Φ10*0.5*7 PCS | |||||
Work Pressure | 0.6Mpa | |||||
Test pressure | 1.2Mpa | |||||
Thermal Insulation | ||||||
Insulation Material | Fiberglass | |||||
Insulation Thickness | 40mm | |||||
Casing | ||||||
Frame | Aluminium alloy | |||||
Frame Colour | Silver/Black | |||||
Back Plate | Galvanized steel | |||||
Sealing Gasket | EPDM | |||||
Packing:
LCL( Less than Container Load ):Wooden case
FCL( Full Container Load ):Export carton
Delivery:
Usually, it is 10 Working days after receiving deposit or original L/C.
|
