| Categories | Tyre Recycling Line |
|---|---|
| Place of Origin: | Jiangsu, China |
| Brand Name: | XD |
| Model Number: | CXFJ-26-1 |
| Certification: | CE CCC ISO CQC |
| Supply Ability: | 200 Set/Sets per Year |
| Packaging Details: | wooden |
| MOQ: | 1 Set/Sets |
| Price: | Negotiable |
| Type: | Open Mixing Mill |
| Voltage: | 380V 50Hz |
| plastic miller: | miller group |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Power(W): | 22+0.75+3 |
| Weight: | 1.5t |
| Warranty: | 1 year |
| Port: | SHANGHAI |
CXFJ Rubber Powder Superfine Miller rubber powder pulverizer
Introduction
Developed by adopting advanced domestic and overseas technology, it is widely used in natural, synthetic rubber and plastic powder production. It is mainly composed of miller, collector, draught fan, cyclone and control cabinet, etc.
Structure and Principle
The machine is composed of one or multiple millers, collector and
control system. The miller consoists of frame, motor, stepless
feeding motor, feeding device, fixed and rotary discs, the basic
principle is to mill and grind rubber into powder by the relative
movement of fixed and rotary discs. Wind and waster cooling system
can ensure the milling output quality. Feeding device use stepless
motor, the feeding speed can be changed according to production
requirements.
With such features as low noise, high output, easy operation and
maintenance, no pollution and even millingsize, etc.
Technical Data
| Model | 26-1 | 26-2 | 26-3 |
| Capactiy(kg/h) | 40~200 | 80~400 | 120~600 |
| Feeding size(mesh) | 5~20 | 5~20 | 5~20 |
| Output size(mesh) | 30~100 | 30~100 | 30~100 |
| Motor powder(kw) | 22+0.75+3 | 22*2+0.75*2+4 | 22*3+0.75*3+5.5 |
| Milling temperatu(º C) | <=80 | <=80 | <=80 |
| Weight(T) | 1.5 | 2.5 | 3.5 |
| Dimension(m) | 2.5*2.5*3.8 | 3.5*2.5*3.8 | 6*2.5*3.8 |
|
