Z2V2 6214 2ZC3 Fag Deep Groove Ball Bearings For Ac Motor , Long Life Time

Categories Deep Groove Ball Bearings
Brand Name: MCBB/ Customization/ Any famous brand
Model Number: 6214 2ZC3
Certification: CE
Place of Origin: Wuxi, Jiangsu
MOQ: NO MOQ, 1pcs is ok.
Price: negotiation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Payment online by credit card, Dirct RMB from abroad
Supply Ability: 30,0000pcs/month
Delivery Time: Within 7days after confirmation
Packaging Details: single PP bag+single color box+hardness carton+pallet
Product name: 6214 2ZC3 deep groove ball bearing 12mm shaft
Weight: 1.084kgs
Inner Diameter: 70mm
Outer Diameter: 125mm
Thickness: 24mm
Cage: steel
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Z2V2 6214 2ZC3 Fag Deep Groove Ball Bearings For Ac Motor , Long Life Time

High Speed Z2V2 6214 2ZC3 Fag Deep Groove Ball Bearing For Ac Motor

Bearing deep groove ball, Description,


1. Reducer bearing 6212ZZ 6213ZZ 6214 6215ZZ RS motor bearing.


2. Deep groove ball bearing 6214-2z, according to the main dimensions of DIN 625-1, sealing on both sides of the gap, its characteristics: radial load, one-way axial load, two-way axial load, bilateral seal, lifetime lubrication, maintenance free, grease lubrication.

Deeo groove ball bearing axial load, Specification,

Bearing Model6214 2ZC3
d70mm
D125mm
B24mm
D2110.7mm
Da max116mm
d186.8mm
da min79mm
ra max1.5mm
m1.11 kg
Cr66000N
C0r44000N
nG5000 1/min
nB6100 1/min
Cur2900 N


Why choose mcbb bearing,

Supporting payment online. 1pcs is ok.

deep groove ball bearing 12mm shaft, Feature,


1. The structure is simple, can obtain the high accuracy, also applies to the high speed rotation.


2. The ball makes point contact with the orbit. The radius of the track groove of the outer wheel and the inner wheel is larger than that of the ball. It can bear radial load, axial load and composite load.


More model of bearings for reference,

Product
Bearing Type
Bore Dia (d) (mm)
Outer Dia (D) (mm)
Width (B) (mm)
6213
Open
65
120
23
6213-2RS
Sealed
65
120
23
6213ZZ
Shielded
65
120
23
6313
Open
65
140
33
6313-2RS
Sealed
65
140
33
6313ZZ
Shielded
65
140
33
6014
Open
70
110
20
6014-2RS
Sealed
70
110
20
6014ZZ
Shielded
70
110
20
6214
Open
70
125
24
6214-2RS
Sealed
70
125
24
6214ZZ
Shielded
70
125
24
6314
Open
70
150
35
6314-2RS
Sealed
70
150
35
6314ZZ
Shielded
70
150
35
6015
Open
75
115
20
6015-2RS
Sealed
75
115
20
6015ZZ
Shielded
75
115
20
6215
Open
75
130
25
6215-2RS
Sealed
75
130
25
6215ZZ
Shielded
75
130
25
6315
Open
75
160
37
6315-2RS
Sealed
75
160
37
6315ZZ
Shielded
75
160
37
6016
Open
80
125
22
6016-2RS
Sealed
80
125
22
6016ZZ
Shielded
80
125
22
6216
Open
80
140
26
6216-2RS
Sealed
80
140
26
6216ZZ
Shielded
80
140
26


Application,


Bearing 6214-2z can also be used for: box-type drying equipment mixer horizontal pump matching machine sheet cutting machine machine tool pad iron rubber mechanical flattening machine shoe repairing equipment belt pulley belt type drying equipment binding machine grooving machine setting machine drilling sleeve cutting machine crosscutting machine nailing machine towing chain spray dryer.

Product pictures show,



If you need this types bearings, welcome contact us for its price list.
