| Brand Name: | Hongwei |
| Model Number: | P5 |
| Certification: | CE,FCC,ROHS |
| Place of Origin: | Shenzhen, China |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 pieces/month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | Wooden Case |
| Usage: | Outdoor |
| Cabinet size: | 960*960mm |
| Tube chip color: | Full Color |
| Brightness: | 6500cd/sqm |
| Warranty: | 2 Years |
| Life span: | 100000hours |
| Module size: | 320*160mm |
| Display function: | Video,Picture,Image,ect |
| Led lamp: | SMD 2727 |
| Scan method: | 1/8 S |
20ft X 15ft 960*960mm Panel Street P5 Outdoor LED Wall Display
Key Features
P5 are suitable for outdoor stage,advertising usage
Parameter
Products’ parameters can help you to select which one you need
| Outdoor led display---Iron cabinet | |||
| Pixel pitch | 3mm | 4mm | 5mm |
| Led lamp | SMD 1921 | SMD 1921 | SMD 2727 |
| Module size | 192*192mm | 256*128mm | 320*160mm |
| 320*160mm | |||
| Scan method | 1/16 S | 1/8 S | 1/8 S |
| 1/10 S | |||
| Brightness | 5000cd/sqm | >=6500cd/sqm | >=6500cd/sqm |
| Pixel density | 111111dots/sqm | 62500dots/sqm | 40000dots/sqm |
| Panel material | Iron cabinet | Iron cabinet | Iron cabinet |
| Panel size | 576*576mm | 768*768mm | 960*960mm |
| 960*960mm | 960*960mm | ||
| Average power consumption | 400w/sqm | 800w/sqm | 650w/sqm |
| Max power consumption | 800w/sqm | 1500w/sqm | 1100w/sqm |
| Best view distance | 3-30m | 4-47m | 5-50m |
| Gray level | 12-14bit | ||
| View angle | H≧140° V≧140° | ||
| Refresh rate | ≧1920 Hz ≧3840 Hz | ||
| Protection level | IP65 | ||
| Control system | Linsn/Colorlight/Novastar | ||
| Frame frequency | ≧50/60 Hz | ||
| Input voltage | 100-120V 200-240V | ||
| Screen life | 100000h | ||
What is P5 LED Video Wall?









|
