| Categories | Thermal Break Strip |
|---|---|
| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Polywell |
| Model Number: | PW-CG |
| Supply Ability: | 100000 Meters per Day |
| Packaging Details: | Linear or Roll |
| MOQ: | 5000 Meters |
| Price: | $0.23 - $0.36 / Meter |
| Certification: | SGS |
| Delivery Time: | 15-20 Working Days |
| Payment Terms: | T/T |
| Type: | Other Heat Insulation Materials |
| Material: | PA66 GF25 |
| Color: | Black |
| Application: | Thermal break aluminum |
| Density: | 1.25-1.35 g/cm3 |
| Refractoriness: | 230-255°C |
| Size: | Customized |
| Length: | 6 Meters/piece |
| Certificate: | SGS |
| Product Name: | HK Shape Extruded Nylon Thermal break strips for Aluminun Windows |
| OEM Service: | Available |
| Port: | Shanghai |
| Company Info. |
| Suzhou Polywell Engineering Plastics Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Over the years, polyamide heat-insulation strip has been widely
used in glass curtain walls due to its good properties and low
cost. Especially Polyamide 66 reinforced by 25% glass fiber thermal
break strips, they are inserted into aluminum window, door and
facade profile for thermal insulation.
The shape HK thermal barrier polyamide strip can prevent the window
frame from dust and water, has a better mechanical performance, is
the first generation and easiest shape of insulating strips.
For the shape HK, we can provide the following size or customize
according to customers' requirements.
High quality, competitive price, free sample support and short lead
time, high mechanical strength, high toughness, high softening
point, good wear resistance, self-lubrication, long-term work at
higher temperatures, high CTI value, excellent electrical
insulation, low smoke and toxicity characteristics.
It is mainly used in insulation broken bridge aluminium products, helping to reduce heat loss or heat gain through the aluminum, and has better performance in terms of power usage.
Name | Specification | Brand | Material |
Nylon Thermal Break Strips | PW-HK02 | Polywell | PA66 GF25 |
Item | Unit | GB/T 23615.1-2009 | PW-Technical specification |
Density | g/cm3 | 1.3±0.05 | 1.28-1.35 |
Linear expansion coefficient | K-1 | (2.3-3.5)×10-5 | (2.3-3.5)×10-5 |
Vicat softening temperature | ºC | ≥230ºC | ≥233ºC |
Melting point | ºC | ≥240 | ≥240 |
Testing for tensile cracks | - | No cracks | No cracks |
Shore hardness | - | 80±5 | 80-85 |
Impact strength(Unnotched) | KJ/m2 | ≥35 | ≥38 |
Tensile strength(longitudinal) | MPa | ≥80a | ≥82a |
Elasticity modulus | MPa | ≥4500 | ≥4550 |
Elongation at break | % | ≥2.5 | ≥2.6 |
Tensile strength(transverse) | MPa | ≥70a | ≥70a |
High temperature tensile strength(transverse) | MPa | ≥45a | ≥47a |
Low temperature tensile strength(transverse) | MPa | ≥80a | ≥81a |
Water resistance tensile strength(transverse) | MPa | ≥35a | ≥35a |
Aging resistance tensile strength(transverse) | MPa | ≥50a | ≥50a |
1. Sample water content less than 0.2% by weight.
2. Norm laboratory condition:(23±2)ºC and (50±10)% relative
humidity.
3. The specifications marked with "a" only applies to I-shape strip
otherwise, the specifications concluded between supplier and buyer
through consultation, shall be written in contract or purchase
order.
Please feel free to contact us if you have any questions.
Lydia
E-mail: lydia@szpolywell.cn
Tel: +86-15601568506 (WhatsApp)
Address: Yangshe Town, Zhangjiagang City, Jiangsu Province, China.
1. Introduce products in detail
2. Recommend suitable solutions
3. Provide with reference information
1. Provide with layout and engineering conditions
2. Inform the processing status
3. Offer related documents
1. Provide installation, commissioning and training
2. Offer spare parts
3. Provide with necessary technical support
The product is based on PA66 resin as basic, add glass fiber, efficient flame retardants and various additives, formed by twin-screw extrusion blending.
Automatic Plastic Granulating Machine
PA66 Granules Making Machine
Automatic Polyamide66 Thermal Break Strips Extruding Machine.
Sample is Free, but the express fee is collect or you pay us the cost in advance.
For the polyamide granules, MOQ is 1 ton. For the thermal break strips, MOQ is 10,000 meters.
You can customize the special shape of polyamide strips. If we didn't meet this shape before, we will make new mold for you, and you should pay for the mold.
You can customize the package style and marks.
For years specializing in polyamide granules and thermal break strips has bestowed us experienced and skilled technical workers and production workers. We promise the stability of products and the high-quality of raw material. Furthermore, we can provide technical support from raw material to the final appliance. Believe in that you can get better products and service with lower price.
We are confident in our products, and pack them well before delivery, so usually you will receive your order in good condition. . Any quality issue, we will deal with it immediately.
Packaging details:For all specifications/shapes, they could be
packaged in linear, the length will be 6 meters, or customized.For
the Shape "I", "C", and some simple shapes, they can be packed in
rolls. 400-600 meters/roll.
Delivery details: shipped in 7-15 working days after payment.
|
