130m3/H Oilfield Drilling Rig Duplex Shale Shaker

Categories Linear Motion Shale Shaker
Brand Name: TR Solids Control
Model Number: TRPS703
Certification: API certificate, ISO9001 certificate
Place of Origin: Xi'an, China
MOQ: 1 SET
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 3000 Sets / Month
Delivery Time: Within 15 days after deposit
Packaging Details: Pallet or wooden case
Capacity: 130m3/h
Motor Power: 1.94+1.0kw
Screen Area: 2.6m2
Double Amplitude: 7mm
Ex Standard: ExdllBt4
Vibration Motion: Balanced Elliptical Motion
Screen Specs.: (700*1250mm)*3pcs
Vibration Strength: ≤7.1G(Adjustabe)
Adjustment Angle: -1°-+5°
Weight: 1630kg
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

130m3/H Oilfield Drilling Rig Duplex Shale Shaker

Duplex Shale Shaker for Drilling Rig ZJ70 Oilfield Equipment


Product Introduction


Shale shaker for solids control are devices that remove drill cuttings from the drilling fluid while circulating and drilling. There are many different designs and research into the best design is constantly ongoing since solids control is vital in keeping down costs associated with the drilling fluid. The basic design consists of large, flat sheets of wire mesh screens or sieves of various mesh sizes that shakes or vibrates the drill cuttings, commonly shale shaker, across and off of the screens as the drilling fluid flows through them and back into the drilling fluids processing system, often called a mud system. This separates the drill cuttings, often called solids, from the drilling fluid so that it can be re-circulated back down the well bore. In oilfield industry, linear motion shale shaker are widely used for drilling mud solids control of oil gas well drilling for rig.


Shale shaker can be used as a primary shale shaker and drying shaker for desander and desilter cones.The linear motion design with Adjustable high G force make our linear motion very popular for any types of drilling including: oil gas drilling, CBM drilling, HDD, water well, geothermal well drilling mud cleaning. The simple but heavy duty design makes our shale shaker have reliable operation with less maintenance.


TR Solids Control can manufacture balanced elliptical shale shaker, high quality liner shale shaker, drying shale shaker. We can meet customers' variable requirements. Clients feedback proved the advantages of our shale shaker in international market. Welcome to contact with us for more details.


Main advantages of our mud shale shaker

  1. Martin or OLI vibration motor.
  2. Overall heat treatment, long time work.
  3. Hopper type feed mode reduces feed speed.
  4. Vibration strength is 7.5G, adjustable.
  5. Screen box angle is mechanical and adjustable.
  6. Wedge-type compaction device facilitates fast replacement of screen.
  7. Schneider or Siemens electrical components.

Technical Parameters of Our Mud Shale Shaker


(Model)TRPS703TRPS585-4TRZS703TRZS585
Vibration MotionBalanced Elliptical MotionLinear Motion
Treatment Capacity130m³/h140m³/h120m³/h130m³/h
Motor Power1.94+1.0kw1.94+1.0kw1.5KW×21.72KW×2
Screen Specs.(700×1250mm)×3(585×1165mm)×4(700×1250mm)×3(585×1165mm)×4
Screen Area2.6m²2.7m²2.6m²2.7m²
Vibration Strength≤7.1G≤7.1G≤7.1G≤7.1G
Double Amplitude7mm7mm6mm6mm
Deck Adjustment-1°~+5°-1°~+5°-1°~+5°-1°~+5°
Ex StandardExdIIBt4 / IECEX / A-TEX
Weight1630kg1618kg1620kg1600kg
Dimension2770×1785×1690mm2966×1600×1280mm2770×1785×1690mm2966×1600×1280mm
RemarkAbove data are tested from the drilling mud with viscosity 45s,and specific gravity 1.2g/cm3.


All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.


Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
