Flat Die Biomass Wood Pellet Machines / Making Wood Pellets At Home Elect Motor Driven

Home-used flat die biomass pellet making machine

Structure of the machine

1. Wheel 2. Base 3. Feed hopper 4. Pellet chute

5. Upper case 6. Lower case 7. Electrical cabinet 8. Gearbox

Function of the machine

The pellet press is fixed with an engine with a power of RP-driven all kinds of different power. Via a drive shaft and the die roller wheels are caused to rotate. The starting material for the production of pellets, for example, sawdust is pressed by the wheels roller in the matrix. Due to the pressure and friction in the die, the starting material is heated to a temperature of 60-80 ° C. As a result of pressure and temperature increase, the material connects to compressed pellets and will have a high strength after cooling. Depending on the material to be pressed, additional binder needs to be added. The diameter of the pellets is determined by the hole diameter of the die. Matrices can be ordered with the following hole diameters: 2.5mm, 4mm, 6mm, 8mm.

Raw materials for the machine

The pellet machine can suitable for nearly all kinds of biomass materials. Like pine, white pine, mahogany, pinus sylvestris, rubber tree, bamboo shavings, rice husk, seeds shells, peanut shells, halm, pennisetum, straw, wheat straw, cor stover, cotton stalks, alfalfa grass, bagassse, palm fiber, paper, non-physical materials.

The final pellets

Output pellets can be as very good fuel, see the following specification about the pellets:

Technical parameter of the pellet machines

Beijing Silk Road Enterprise Management Services Co.,LTD is one of the leading suppliers of biomass pellet making machinery in China. We adopted Germany design and technology, 15 years manufacturing experience and 10 years exporting experience, can provide you wide range of capacity, low energy consumption, high stability equipment. Choose us, you will get a very trustworthy partner.

We have more than 10 years exporting experience about the biomass machinery. And choose us, you will get a very trustworthy partner. The quality of our products and service of our sales are A-class.
