| Categories | 1.25G SFP Optical Module |
|---|---|
| Place of Origin: | Hubei, China |
| Brand Name: | YXFiber |
| Model Number: | YXF-P1A6-LCD/YXF-P1B6-LCD |
| Certification: | CE RoHS FCC |
| MOQ: | 1pair |
| Price: | $14.50/pair |
| Packaging Details: | 10pcs in Plastic tray |
| Delivery Time: | 1~3working days after payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Type: | Fiber Optic Transceivers |
| No. of Fiber: | 1. |
| Use: | FTTX |
| Supply Voltage: | 3.3V |
| Data rate: | 1.25G |
| Power: | 2~-3dBm |
| Wavelength: | 1310nm/1490nm |
| Transmission distance: | 60km |
| Interface: | BIDI LC |
| Fiber Type: | SMF |
| DDMI: | Yes |
| Warranty: | 1 Year |
| Selling Units: | Single item |
| Single package size : | 22X5X6 cm |
| Single gross weight: | 0.060 kg |
| Package Type: | 10pcs/ anti-static box |

l Up to 60km transmission on SMF
l Up to 1.25Gbps
l 1310nm DFB laser
l Single LC/SC receptacle optical interface compliant
l 2-wire interface for integrated DDM, DOM
l SFP Package
l +3.3V power supply
l CE ROHS ISO9001 FCC certificate
l Operating case temperature: 0~+70°C
1 year warranty
Specification
Absolute Maximum Ratings | |||||
Parameter | Symbol | Min. | Max. | Unit | Notes |
Storage Temperature | TS | -40 | +85 | ℃ | |
Supply Voltage | VCC3 | 0 | 3.6 | V | |
Relative Humidity | RH | 5 | +85 | % | Note1 |
Rx Input Average Power | Pmax | - | +1 | dBm | |



|
