| Categories | Aluminum Alloy Door |
|---|---|
| Brand Name: | Huilv |
| Model Number: | HL |
| Certification: | ISO9001:2008/ ISO14001:2004/ OHSAS 18001:1999/PPG/TUV/CE |
| Place of Origin: | China |
| MOQ: | 300Kg |
| Payment Terms: | D/A, L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000Tons/Year |
| Delivery Time: | Within 5-15 working days |
| Packaging Details: | Standard packing: *Transparent protection film, or cotton paper to protect each piece. *Transparent PE film outside each bundle/or Kraft paper. *Small profile to be inserted into bigger ones to save space EP paper inside for each piece then shrink pape |
| Product name: | Waterproof T5 6000 Series Recyclable Aluminum Alloy Door |
| Temper: | T3-T8 |
| Application: | Door & Window |
| Lead Time: | 15-20 Working Days |
| Color: | black, Silver, bronze, White, Champagne |
| Type: | OEM Aluminum Extrusions Profiles |
| Port: | Wuhu, Nanjing, Shanghai |
| Thickness: | 0.8mm~5mm |
| Recyclable: | Yes |
Highly Sealed Highly Waterproof And Corrosion Resistant Aluminum Doors 6000 Series T3-T8
| Material | 6000series |
| Temper | T3-T8 |
| Thickness | General profiles thickness: 0.8 - 5.0 mm; |
| Anodized protection thickness: 8 - 25 um; | |
| Powder coating color thickness: 40 - 120 um. | |
| Length | According to your requirement,Max 6.4 meters |
| Shape | Square, Rectangle, Round, Flat, Angle, T profile etc. |
| Surface Treatment | Anodized,powder coated,sand blasted, polishing,mill finish,etc |
| Color | silver, champagne, black, white, mirror, customized request available. |
| Application | Windows and doors, curtain walls, glass wall, furniture, ceiling,sunroom, green house, rack, handrails, formwork, kitchen, LED strip, transportation rail, vehicles, motor housing, machine, tent, solar. Industrial profile, Decoration profile etc. |
| Optional Machining | Cutting,drilling,chamfering,stamping,CNC milling,etc |
| OEM service | Available for aluminum profiles |
| Characteristics | Strong, stylish, durable, corrosion-resistant. |
| Packing Details | Inside : packed with plastic film to protect each piece. |
| Outside: Wrap to be bundles by waterproof craft paper or EPE film. | |
| Customized as customers request is available. |
Chemical Composition
| Alloy | Chemical Composition | |||||||||
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al(Min) | |
| 6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.4-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | rest |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | rest |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | rest |
Mechanical Properties
| Alloy | Temper | Thickness | T.S. | Y.S | ELOG. | Hardness | |
| σb (MPa) | σ0.2 (MPa) | δ% | HV | HW | |||
| 6005 | T5 | ≥ 0.8 | ≥260 | ≥240 | ≥10 | ≥85 | ≥15 |
6063 | T4 | ≥ 0.8 | ≥130 | ≥65 | ≥12 | - | - |
| T5 | ≥ 0.8 | ≥160 | ≥110 | ≥8 | ≥58 | ≥8 | |
| T6 | ≥ 0.8 | ≥205 | ≥180 | ≥8 | ≥65 | ≥10 | |
| 6061 | T4 | ≥ 0.8 | ≥180 | ≥110 | ≥16 | ≥65 | ≥10 |
| T6 | ≥ 0.8 | ≥265 | ≥245 | ≥8 | ≥85 | ≥15.5 | |
Our Advantage
Why Choose us?
FAQ:
Q1:Do you make customized products based on our design drawings?
Re: Yes, we are a professional aluminum extrusion profiles factory with an experienced engineering team, to make custom products according to clients’ drawings.
Q2: Will my drawing be safe after you get it?
Re: Yes, we will not release your design to any third party unless with your permission. And we can sign the NDA before you send the drawing if you need.
Q3: Is it different surface treatment, the same price?
Re: No, the price of the plating is higher than the anodic oxidation. The prices will be quoted as per your specific requirement.
Q4. If I choose plating process, all color can do?
Re: No, plating process with current technology can't be all color. However several hot-sale conventional color is available, such as: black, white, gray, silver, gold, etc. As customers require.
Q5: How to visit your factory?
Re: Welcome to our factory, we can pick you up.
|
