Spherical Roller Thrust Bearing Manufacturing Machinery Roller Bearing
Description:
| Model | 51300 series |
| Bearing material | GCr15/AISI52100/100Cr6 |
| ID*OD*W (mm) | 90 x 155 x 50MM |
| Seal type | double shields |
| Lead time | Stock or 15-30days |
| Weight(kg) | 3.8 |
| Basic dynamic load ratings/C | 182 kN |
| Basic static load ratings/C0 | 440 kN |
| Limiting speed | 2200 r/min |
| Clearance | C2,C0,C3,C4,C5 |
| Vibration Level | V1,V2,V3,V4 |
| Precision Rating | P0,P6,P5, |
| MOQ | No MOQ |
| Port | Shanghai |
| Grease | Mobil polyrex EM,Kyodo Yushi SRL |
| Payment terms | T/T, L/C |
| Number | Specification | Rated Load(KN) | Speed(r/min) | Weight | ||||
| D(mm) | D(mm) | W(mm) | Cr(N) | Cor(N) | Grease | Oil | kg | |
| 51100 | 10 | 24 | 9 | 10 | 14 | 6500 | 10000 | 0.02 |
| 51101 | 12 | 26 | 9 | 10.3 | 15.4 | 6500 | 10000 | 0.022 |
| 51102 | 15 | 28 | 9 | 10.5 | 16.8 | 6100 | 9400 | 0.024 |
| 51103 | 17 | 30 | 9 | 10.8 | 18.2 | 6100 | 9400 | 0.028 |
| 51104 | 20 | 35 | 10 | 14.2 | 24.7 | 5100 | 7900 | 0.04 |
| 51105 | 25 | 42 | 11 | 19.5 | 37.2 | 4400 | 6800 | 0.059 |
| 51106 | 30 | 47 | 11 | 20.4 | 42.2 | 4300 | 6600 | 0.068 |
| 51107 | 35 | 52 | 12 | 20.4 | 44.7 | 3900 | 6000 | 0.09 |
| 51108 | 40 | 60 | 13 | 26.9 | 62.8 | 3400 | 5300 | 0.12 |
| 51109 | 45 | 65 | 14 | 27.8 | 69.1 | 3200 | 5000 | 0.15 |
| 51110 | 50 | 70 | 14 | 28.8 | 75.4 | 3100 | 4800 | 0.16 |
| 51111 | 55 | 78 | 16 | 34.8 | 93.1 | 2800 | 4300 | 0.24 |
| 51112 | 60 | 85 | 17 | 41.4 | 113 | 2600 | 4000 | 0.29 |
| 51113 | 65 | 90 | 17 | 41.7 | 117 | 2400 | 3700 | 0.34 |
| 51114 | 70 | 95 | 18 | 43 | 127 | 2300 | 3600 | 0.36 |
| 51115 | 75 | 100 | 19 | 42.3 | 127 | 2200 | 3400 | 0.42 |
| 51116 | 80 | 105 | 19 | 44.6 | 141 | 2100 | 3300 | 0.43 |
| 51117 | 85 | 110 | 19 | 45.9 | 150 | 2100 | 3200 | 0.46 |
| 51118 | 90 | 120 | 22 | 59.7 | 190 | 1900 | 2900 | 0.68 |
| 51120 | 100 | 135 | 25 | 85 | 268 | 1600 | 2500 | 0.99 |
| 51122 | 110 | 145 | 25 | 87.1 | 288 | 1600 | 2400 | 1.08 |
| 51124 | 120 | 155 | 25 | 89 | 308 | 1500 | 2300 | 1.16 |
|
