| Categories | Woodworking Thicknesser Machine |
|---|---|
| Brand Name: | Easwon |
| Model Number: | MB523F |
| Certification: | CE |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | negotiated |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 sets per month |
| Delivery Time: | 15 days |
| Packaging Details: | wooden case |
| Model: | MB523F |
| Max. planing width: | 300mm |
| Planing depth: | 4mm |
| blade number: | 3pcs |
| Cutting diameter: | 87mm |
| Workbench length: | 1800mm |
| Motor power: | 2.2kw |
| Warranty: | 1 year |
| Condition: | New |
Precision casting iron table, the seam of high precision.
Elegance of the guider structure, convenient and reliable

![]() | ![]() |
| The belt cover is installed with hinges and attracted by powerful magnets, which is convenient for blade installation and belt replacement. | High-precision planing cutter shaft, processing surface is smooth, can be equipped with spiral cutter shaft as per request. |
![]() | ![]() |
| Practical guide plate mechanism, easy to operate, flexible and reliable. | Using 2500mm ultra-long precision cast iron workbench, after special processing, good flatness, durability and no deformation, high precision of stitching |
| Technical specification | Unit | MB523M | MB524M |
| Max.planing width | mm | 300 | 400 |
| Max. planing depth | mm | 4 | 5 |
| Spindle speed | r/min | 5600 | 5000 |
| Blade number | pcs | 3 | 4 |
| Cutting diameter | mm | Ø87 | Ø102 |
| Workbench total length | mm | 1800 | 2500 |
| Motor power | kw | 2.2 | 3 |
| Motor speed | r/min | 2840 | 2880 |
| Overall dimension | mm | 1800x740x1010 | 2500x810x1050 |
| Net weight | kg | 300 | 440 |
