| Categories | Switchable Transparent Film |
|---|---|
| Brand Name: | UPASS |
| Model Number: | Youguang |
| Certification: | ISO9001 |
| Place of Origin: | China |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | TT/LC |
| Supply Ability: | 600 Tons/Month |
| Delivery Time: | Negotiable |
| Packaging Details: | Wooden Pallet |
| Thickness: | 2mm-5mm |
| Width: | 600-2000mm Can be customized |
| Total Light Transmittance: | Power Off ＞67% |
| Directional Light Transmittance: | Power Off ＜4% |
| Haze: | Power Off ＞96% |
| Application: | Used for the building of decorating, remodeling, advertising |
| Company Info. |
| Upass Material Technology (Shanghai) Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
STF (Switchable Transparent Film) is also known as PDLC (Polymer Dispersed Liquid Crystal) film, electronic dimming film, electronic curtain, etc.
It is based on film technology. The rod-shaped polymer liquid crystalls mixing with prepolymer stick to transparent conductive base material,
so that it simultaneously possesses charateristics of liquild and crystal. When powering off, polymer comes to the atomization of disorder.
With polymer powering on, it is orderly arranged along with the direction of the electric field, which enables the film to have transmittance of the light.
By controling the electric switch, It can be converted between transparent and opaque state.
The picture shows the principle diagram of the STF.
The swichable liquid crystal transparent film is also called an electronically controlled smart PDLC flm.
lt consists of two layers of flexible transparent conductive films (ITO film and PDLC).
By controlng the electic field, It is switchable between the transparent and opaque (atomized) state.
The parameters of YOUGUANG smart film are as follows:
| Item | Performance / Unit | Testing Method and Standard | |
| Rated Voltage | ON | 36/48/60(AC50HZ) | Multimeter |
Power Consumption | ON | 4-6w/(SQM) | Multi-parameter Electrical Measuring Instruments |
| Total Light Transmittance | ON | ＞83% | GB/T 2410-2008GB/Spectrophotometer |
| OFF | ＞67% | ||
| Directional Light Transmittance | ON | ＞80% | GB5137.2-2002 |
| OFF | ＜4% | ||
| Haze | ON | ＜4% | GB/T 2410-2008GB/Spectrophotomete |
| OFF | ＞96% | ||
| Response Time | ON | ＜40(MS) | Liquid Cystal Mutl-prareter. Measuring Instrument |
| OFF | ＜210(MS) | ||
| Operating Temperature | / | -30~70℃ | Constant Temperature and Humidly Testing Machine |
| Lifetime | ON | ＞100000(H) | GB18910.5- 2008 |
|
