HOWO Chassis 15 Ton Water Tanker Fire Truck Gross Weight 33000kg Max Power 294Kw

HOWO Chassis 15ton Water And Foam Fire Truck Gross Weight 33000kg 294kw Max Power

Pipeline

Liquid tank

Dry powder tank

• Dry powder filling capacity: 500Kg
• Working pressure: 1.2 ~ 1.4MPa
• Dry powder tank is a pressure vessel which is mainly welded by Q345R material. It is made of feeding powder port, discharging powder port, nitrogen delivery pipe and discharge powder tube, tank nitrogen delivery pipe is a ring shape which is equipped with multiple intake valves, so that gas and powder can mixing uniformly, with fluidized state. The design of intake valve makes dry powder be inaccessible to nitrogen gas delivery pipe.
• All cylinders are placed in a bottle rack to supply gas for dry powder tank. Nitrogen cylinder group is consisting of nitrogen cylinder, bottle valve, high pressure gauge, air inflation connection, high pressure ball valves and other components.

Dry powder monitor (1 pcs)

• Model: PF40
• Effective spray rate: ≥40 Kg / s
• Shot range: 40 ~ 45m
• Rotation angle: horizontal 360 °, pitching -15 ° ~ 80 °
• Dry powder gun and hose reel: 2 sets (30m)
• Effective spray rate: 5Kg/s
• Shot range: ≥12m
• Pressure reducing valve and safety valve
• This device use Chinese reducing valve. It is a special pressure reducing valve of dry powder fire extinguishing equipment which has features of reliable performance, small size, large gas supply, safety and convenience.

Dry powder system control box
Equipped with air source main valve, air filter, in the electric steering box is equipped with solenoid valve, fuse boxes, relay, binding post and so on.
