50-350mm Dia 36CrNiMo4 DIN 1.6511 Steel Round Bar Hot Forged 36CrNiMo4 Steel Bar

50-350mm Dia 36CrNiMo4 DIN 1.6511 Steel Round Bar Hot Forged 36CrNiMo4 Steel Bar

50-350mm Dia 36CrNiMo4 DIN 1.6511 Steel Round Bar Hot Forged 36CrNiMo4 Steel Bar
50-350mm Dia 36CrNiMo4 DIN 1.6511 Steel Round Bar Hot Forged 36CrNiMo4 Steel Bar
Categories Steel Round Bar
Brand Name: Mittel
Model Number: 36crnimo4
Certification: SGS ISO MTC
Place of Origin: China
MOQ: 100KGS
Price: 1.85 USD/KG
Payment Terms: L/C, T/T
Supply Ability: 80000KGS
Delivery Time: 7 Working Days
Packaging Details: Wooden Pallet BOX
Steel grade: Alloy Steel
Alloy or not: Is Alloy
Technique: Hot Rolled,Forged
Application: Structural Steel Bar,Die Steel Bar
Type: Alloy Steel Bar
Standard: ASTM
Shape: Round
Length: 1--12m
Surface: black or bright,Polished
Diameter: 12mm-650mm
Heat treatment: Normalized +Annealed +Quenched + Tempered
Contact Now
Company Info.
JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

50-350mm Dia 36CrNiMo4 DIN 1.6511 Steel Round Bar Hot Forged 36CrNiMo4 Steel Bar

Supply FormSize(mm)ProcessTolerance



Round		Φ6-Φ100Cold DrawnBright/BlackBest H11

Φ16-Φ350
Hot Rolled		Black-0/+1mm
Peeled/groundBest H11

Φ90-Φ1000
Hot Forged		Black-0/+5mm
Rough Turned-0/+3mm

Flat/Square/Block		Thickness :120-800
Hot Forged		Black-0/+8mm
Width:120-1500Rough Machined-0/+3mm

TECHNICAL DATA SHEET - DIN 36CrNiMo4

MATERIAL CATEGORY: hardened and tempered steel
PRODUCT DESCRIPTION
Alloy structural steel is provided with higher yield strength, tensile strength, endurance strength, yield ratio (about 0.85 generally ) enough plasticity and toughness.
The concentration of alloy element of this kind of steel is quite high, mainly are corrosion resistant steel, heat resistant steel, wear resistant steel, and other special steels of physical and chemical properties. Alloy structural steel has preferable mechanical property than that of carbon structural steel, high performance of heat treatment especially.
The alloy is usually produced by EAF /VD /LF followed by electroslag refining (ESR) if necessary for special purpose.
Bars and, where applicable, forgings are subjected to ultrasonic examination based on the different level according to the buyers' requirements.
Bars are usually supplied bright in the annealed condition, or bright annealing specially.
Final heat treatment - heat treatment / QT
MATERIAL SPECIFICATIONS
DIN EN 10083-2 (2006), DIN 17200 (1987)
CHEMICAL COMPOSITION (WEIGHT %)
C (％): 0.32 ~ 0.40
Si (％): ≤ 0.40
Mn (％): 0.50 ~ 0.80
P (％)≤: 0.035
S (％)≤: 0.035
Cr (％): 0.90 ~ 1.20
Mo (％): 0.15 ~ 0.30
Ni (％): 0.90 ~ 1.20
MECHANICAL PROPERTIES - HOT WORKING, HEAT TREATMENT AND HARDNESS
|Quenching |hot working temp./℃|First: 850
|quenching|hot working temp./℃|Second: —
|quenching|cooling medium: oil
|tempering|hot working temp./℃: 600
|tempering |cooling medium: water, oil
Tensile strength, |σb/MPa|≥: 980
Yield strength, |σs/MPa|≥: 835
Elongation, |δ5(％)|≥: 12.0
Reduction of area, |ψ(％)|≥: 55.0
Impact, |AKV/J|≥: 78
Hardness / HBS|≥: 269
TYPICAL APPLICATIONS
Alloy structural steels are widely used in the filed of ship, vehicle, airplane, guided missile, weapons, railway, bridges, pressure vessel, machine tools, mechanical components with a bigger sectional size and so on.
Mechanical gears, gear shaft, main axis, valve rod
Mechanical parts - connecting rod, bolt and nut
Multidiameter shaft
Pressure vessel, seamless pipe
PRODUCT PROFILE
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Square bar / Flat bar: 3mm to 1000mm
Plate / Steel strip: 0.1mm to 1000mm
Width: 8mm to 1200mm
Steel sheet: thickness 0.50 ~ 6.00mm, width 1000mm X length 1000/2000mm - Standard size
Length: random length or based on the customer's special requirement
Forged steel shape: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM
Pipes / Tubings: OD30 - 1200 mm, with wall thickness ranging from 15 to 350 mm
