| Categories | Indoor Full Color LED Screen |
|---|---|
| Brand Name: | XGC |
| Model Number: | P5 |
| Certification: | CE ,FCC, ROSH CCC |
| Place of Origin: | Shenzhen,China |
| MOQ: | 1PCS/ 1 ㎡ |
| Price: | USD360--USD600 /㎡ |
| Payment Terms: | T/T、, Western Union、L/C、, D/A、, D/P, MoneyGram |
| Supply Ability: | 5000㎡ per month. |
| Delivery Time: | 7-15 days |
| Packaging Details: | Plywood case、flight case |
| Product name: | P5 Indoor Led Display |
| Cabinet size: | 640*640mm,640*960mm,or Customized |
| Application: | Hotel,meeting room,station, airport, stadium,etc |
| Display function: | Video,image,text. |
| Warranty: | 3 Years |
| Led chip: | Nationstar |
| Life span: | more than 11 years |
| Weight: | 9kg/pcs |
| Power supply: | Chuanglian 110~220V |
| Crontroller: | Novastar,Colorlight, Linsn,etc. |
Bar DJ Large LED Screen P5 Indoor 640X640mm LED Display
Features:
♦ 1. Cabinet weight is 9kg.
♦ 2. Ultra-thin high strength, toughness, high precision die-cast aluminum cabinet.
♦ 3. High precision-the size is electromechanical processing
accurate to 0.1mm
♦ 4. Compatible-new structure design, meet lifting and stacking
requirements, and meet indoor and outdoor requirements;
♦ 5. Fast-Installation .The cabinet is connected with up and down,
left, right, and fast locking mechanism,10 seconds to complete the installation of a cabinet.
| Technical Parameter for P5 INDOOR RENTAL LED DISPLAY | |||
| Module Specifications | |||
| 1 | Pixel Pitch | 5mm | |
| 2 | Led Type | SMD2121 | |
| 3 | Pixel configuration | 1R1G1B | |
| 4 | Module Size | 320x160mm | |
| 5 | Module Resolution | 64x32pixels | |
| 6 | LED Chip | Epistar | |
| 7 | LED brand | Hongsheng/Forest/ Kinglight/Nationstar/ | |
| Cabinet Specification | |||
| 1 | Cabinet Size | 640x640mm | |
| 2 | Cabinet Resolution | 128x128 pixels | |
| 3 | Module Qty. | 2x4pcs | |
| 4 | Power Supply | 5V40A 200W/ 5V60A 300W | |
| 6 | Cabinet Materials | DIE CASTING ALUMINUM | |
| Screen Parameters | |||
| 1 | Pixel density | 40000dots/㎡ | |
| 2 | Screen Resolution | according to screen size | |
| 3 | Cabinet Qty. | according to screen size | |
| 4 | Brightness | ≥1200 CD/sqm | |
| 5 | Refresh rate | ≥1920Hz/s | |
| 6 | Scanning Mode | 1/8 scan | |
| 7 | Viewing Angle | H:140°;V:140° | |
| 8 | Viewing Distance | ≥5m | |
| 9 | Gray Level | 16 Bit | |
| 10 | Power Input | AC110~240V | |
| 11 | Power Comsuption | Max: 1000W/㎡ Average:300W/㎡ | |
| 12 | MTBF--hours | >10,000 hours | |
| 13 | Life--hours | ≥100,000 hours | |
| 14 | IP Grade | IP40/IP30 | |
| 15 | Operating Temperature | -35℃~ 65℃ | |
| 16 | Storage Humidity | 10℃~70℃RH | |
| 17 | Control System | Colorlight/Nova/Linsn | |
| 18 | Operating System | Windows98/me/2000 /NT/XP | |
| 19 | Power Supply | 5V40A 200W/5V60A 300W | |
| 20 | Maintance Access | Back service/Front service | |
| 21 | Video processor | Colorlight/ Novastar/ Linsn/ VDWALL/ RGBLINK/ KYSTAR | |
| 22 | Control mode | computer /USB/WIFI/4G | |
HS code: 8528591090
Regular package:
1.How long could I receive the inquiry reply?
A:You will get a reply within 24 hours.
2.What kind of led display do you offer?
A:Different product offer different time frame warranty, but all product here we offer 1 year at least warranty
3.How is the after sales service?
A:We have a professional team which is in all around the world, also a service hot-line dealing with your complains and feedback. We also offer 24-hour online service to help you solving problems
4.How long will it take to deliver goods?
A:We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment
|
